Lvl Materials SPECS Qt
Part Location
.1 BAGL-55A WIRE CLIP 2.000 23
.1 CN1020001504
CONN WIRE 10P 2.0 150MM FEMALE/FEMALE
1.000 20
.1 FFC5005002001 FFC 50P 200MM PITCH 0.5MM-ROH 1.000 19
.1 LAC22AKA95
ABLETON APC EDITION SERIAL NO STICKER(ADA1&ADA3)
1.000 22
.1 LAC52ALE01 LABEL (SAFETY) 1.000 21
.1 MT0601802 HEAT METAL 2.000 24
.1 MT1504432 T3 SHOULDER SCREW 6.000 11
.1 MT153031301 BOTTOM PLATE(SPRAY & PRINT) 1.000 15
.1 NM1504403 VELVET CARPET 9.000 18
.1 PT1304315 POWER CABLE RETAINER 1.000 10
.1 PT151063801 SLIDE KNOB (ADD WHITE INK) 9.000 1
..2 PT1510638 SLIDE KNOB 1.000
.1 PT1510643
KNOB (ALPHA) (SHARING TOOL AL9-11-1011)
1.000 7
.1 PT152062001
ADA3 SIDE CAP LEFT(SPRAY RUBBER PAINT)
1.000 6
..2 PT1520620 ADA3 SIDE CAP LEFT 1.000
.1 PT152062101
ADA3 SIDE CAP RIGHT(SPRAY RUBBER PAINT)
1.000 5
..2 PT1520621 ADA3 SIDE CAP RIGHT 1.000
.1 PT153001601
TOP PANEL ADA3 (SPRAY & PRINT APC20)
1.000 3
..2 PT1530016 TOP PANEL ADA3 1.000
.1 RU1504315 RUBBER KEYPAD 1.000 12
.1 RU1530601 RUBBER FOOT 4.000 17
.1 SC0306RINI SCREW 3.000 8
.1 SC0308RBBI SCREW 16.000 16
.1 SC0308RBNI SCREW 23.000 4
.1 SC0310RIBI SCREW M3 X 10 1.000 9
.1 TP0316B
BLACK ACETATE CLOTH TAPE W16MM X L30M
0.002 25
.1 TWPC08A00903 PCB ASS'Y (MAIN) 1.000 14
..2 AL0-17-2470
RES C.ARRAY 4X47 OHM 1/16W 5% ISOLATED C-C=0.5MM
7.000 R11, 18 , 20 , 24~26 , 29
..2 AL0-17-8103 Array Resistor 8 X 10k 1/16 W 5% 2.000 R13, 14
..2 AL1-70-1471 CAP. 4.7UF/6.3V TANT-A SMD 20% 1.000 C6
..2 AL2-51-0340 DIODE SCHOTTKY MBRA340T3 40V 3A 2.000 D1, 4
..2 AL2-51-4401 TRANS NPN 2N4401 40V 1A SOT-23 2.000 Q2, 3
..2 AL2-56-0749 Transistor FZT749 SOT-223 1.000 Q1
..2 AL2-61-3463 IC REG VOLTAGE MC34063A ADJ 1.000 U3
..2 AL2-61-7223
IC REG VOLTAGE NJU7223DL1-33 3.3V TO-252
1.000 U4
..2 AL2-61-7885 IC UA7805 CKTTR TO-263-DR51 1.000 U1
..2 AL4-21-5000 Connector 50P 0.5MM SMD-ROHS 1.000 J1
..2 CS102K5003X7R
CHIP CAP 1000PF/50V,X7R,+/-10%, SMD 0603
6.000 C3 , 9, 11~12, 15, 17
..2 CS103K5003X7R C.CAP 0.010UF 50V X7R,±10% SMD 0603 1.000 C7
..2 CS104K5003X7R
CHIP CAP 0.1UF/50V,X7R,+/-10%, SMD 0603
13.000 C8, 10, 13~14, 16, 18~19, 21~22,
C31~34
..2 CS180J5003NPO CHIP CAP. SMD 18pF/50V 0603 NPO 2.000 C1~2
..2 CS221J5003NPO C. CAP. SMD 220 pF 50V 5% 0603 NPO 1.000 C20
..2 ICSTM32F102R8T6 IC STM32F102R8T6 TQFP64-DR376 1.000 U2
..2 PC08A009 PCB 4 layer FR-4 175*80MM 1.000
..2 RS000004F06 CHIP RES. 0 O 1% SMD 1206 2.000 R30, 45
..2 RS000008J05 CHIP RES. 0 5% SMD 0805 3.000 R1, 2, 17
..2 RS000010J03 CHIP RES. 0 1% SMD 0603 10.000 R3~9, 42, 46, 47
..2 RS000108J05 CHIP RES. 1 5% SMD 0805 1.000 R15
..2 RS001K10F03 CHIP RES. 1K 1% SMD 0603 3.000 R22, 31, 33
..2 RS002210F03 CHIP RES. 22 1% SMD 0603 2.000 R35~36
..2 RS010K10F03 CHIP RES. 10K 1% SMD 0603 5.000 R12, 16, 19, 23, 44
..2 RS012008F05 CHIP RES. 120 1% SMD 0805 1.000 R21
..2 RS01K510F03 CHIP RES. 1.5K 1% SMD 0603 1.000 R37
..2 RS022010F03 CHIP RES. 220 1% SMD 0603 1.000 R10
..2 RS036K10F03 CHIP RES. 36K 1% SMD 0603 1.000 R43
..2 RS047K10F03 CHIP RES. 47K 1% SMD 0603 1.000 R38
..2 RS12318F05 CHIP RES 12K OHM 1/10W ±1% 0805 1.000 R27
..2 RS196218F05 RES 19.6K OHM 1% 0805 1.000 R28
..2 TCS106M1006
TAN-CAP 10UF/10V (A CASE )SND A CASE
1.000 C23
APC20 BOM
