INSTALLATION
02
PRECAUTION S
Cho os e the moun ting loc at ion whe re the un it wi ll no t int erfere wi th the normal
fun ction of the dr iver.
driving
Bef ore final ly inst alling the uni t, conne ct the wiring tem por ar ily and make sur e
it is all
connected up properly and the unit and the system work properly.
Use onl y the par ts incl uded wi th the uni t to ens ure proper inst allation. The use
of unauthorized
parts can cause ma lfunctions.
Consult with your nearest dealer if instal lation requi res the drilling of holes or
other
modif icati ons of the vehic le.
Install the unit where it does not get in the driver's way and cannot injure the passenger if
there is a sudden stop. Like an emergency stop.
Avoid installing the unit where it would be subject to high temp erature, such
as from direct
sunlight, or from hot air, form the heater, or where it would be
subject to dust, dirt or excessive
vibration.
DIN FRON T-MOU NT (Me thod A)
1.Frame
2. Insert fingers into the groove in the front of frame and pull out to remove t he frame.
(When reattaching the frame,point the side with a groove downwards and attach It.)
3.Lever
Insert the levers supplied with the unit into the grooves at both sides of the unit and
shown in figure until they click. Pulling the levers makes possible to remove the
2
1
3
Removing the unit
To Next Page
