Akai CFTD2011 - Page 22

20
MAIN BOARD PARTS LIST
CAPACITOR
C221 PVE039542-2220 2200uF16V20% 85'C D10xL2
5
C222 PZL439640-4750 4.7 uF 16V +80-20%
C223 PYL456470-5620 0.0056 uF 50V 10%
C224 PXL439670-1040 0.1uF 50V +80% -20%
C225 PVE039542-2220 2200uF16V20% 85'C D10xL2
5
C226 PVX270483-4740 0.47 uF 63V10% -55'~+125'
C227 PYL410370-3910 390 pF 50V 5%
C228 PME039570-1080 0.1 uF 50V 20% 5x11mm
C229 PYL410370-1000 10 pF 50 V 5%
C23 PME039540-4700 47 uF16V20%SIZE=5x11mm
C230 PZL456460-1050 1uF 35V 10%
C231 PVE039542-2220 2200uF16V20% 85'C D10xL2
5
C232 PXL439670-1040 0.1uF 50V +80% -20%
C233 PZL439640-4750 4.7 uF 16V +80-20%
C234 PYL456470-5620 0.0056 uF 50V 10%
C235 PXL439670-1040 0.1uF 50V +80% -20%
C236 PVE039542-2220 2200uF16V20% 85'C D10xL2
5
C237 PVX270483-4740 0.47 uF 63V10% -55'~+125'
C238 PYL410370-3910 390 pF 50V 5%
C239 PME039570-1080 0.1 uF 50V 20% 5x11mm
C240 PYL410370-1000 10 pF 50 V 5%
C241 PME039540-1010 100uF16V20%SIZE=5x11mm
C242 PXL439670-1040 0.1uF 50V +80% -20%
C243 PME039540-4700 47 uF16V20%SIZE=5x11mm
C245 PME039540-4700 47 uF16V20%SIZE=5x11mm
C247 PME039550-1000 10 uF 25V 20% 5x11mm
C248 PME039550-1000 10 uF 25V 20% 5x11mm
C25 PME039540-1010 100uF16V20%SIZE=5x11mm
C26 PME039540-1010 100uF16V20%SIZE=5x11mm
C27 PXL439670-1040 0.1uF 50V +80% -20%
C28 PXL439670-1040 0.1uF 50V +80% -20%
C29 PXL439670-1040 0.1uF 50V +80% -20%
C3 PBE039542-1011 CHIP VER 100 uF 16V 20%
C30 PME039540-4700 47 uF16V20%SIZE=5x11mm
C301 PXL439670-1040 0.1uF 50V +80% -20%
C302 PXL439670-1040 0.1uF 50V +80% -20%
C303 PXL456470-1020 0.001 uF 50V 10%
C304 PXL456470-1020 0.001 uF 50V 10%
C305 PXL456470-1020 0.001 uF 50V 10%
C306 PME039540-4700 47 uF16V20%SIZE=5x11mm
C307 PXL456470-1020 0.001 uF 50V 10%
C31 PME039540-1010 100uF16V20%SIZE=5x11mm
C34 PXL439670-1040 0.1uF 50V +80% -20%
C35 PXL439670-1040 0.1uF 50V +80% -20%
C37 PME039570-3390 3.3 uF 50V 20%
C38 PXL439670-1040 0.1uF 50V +80% -20%
C39 PXL439670-1040 0.1uF 50V +80% -20%
C4 PXL439670-1040 0.1uF 50V +80% -20%
C40 PXL439670-1040 0.1uF 50V +80% -20%
CAPACITOR
C41 PXL439670-1040 0.1uF 50V +80% -20%
C42 PME039570-4790 4.7 uF 50V 20% SIZE=5x11m
m
C43 PXL439670-1040 0.1uF 50V +80% -20%
C44 PXL410370-3000 30 pF 50V 5%
C45 PXL410370-3000 30 pF 50V 5%
C46 PXL439670-1040 0.1uF 50V +80% -20%
C47 PME039550-1000 10 uF 25V 20% 5x11mm
C48 PXL456470-1520 0.0015 uF 50V 10%
C49 PXL410370-4710 470 pF 50V 5%
C5 PBE039542-1011 CHIP VER 100 uF 16V 20%
C50 PXL439670-1040 0.1uF 50V +80% -20%
C501 PXL410370-120Z 12 pF 50V 5%
C503 PXL439670-1040 0.1uF 50V +80% -20%
C51 PME039550-1000 10 uF 25V 20% 5x11mm
C52 PXL439670-1040 0.1uF 50V +80% -20%
C53 PME039550-1000 10 uF 25V 20% 5x11mm
C536 PXL439670-1040 0.1uF 50V +80% -20%
C537 PXL439670-1040 0.1uF 50V +80% -20%
C538 PME039550-1000 10 uF 25V 20% 5x11mm
C539 PME039540-1010 100uF16V20%SIZE=5x11mm
C54 PXL456470-1520 0.0015 uF 50V 10%
C540 PXL439670-1040 0.1uF 50V +80% -20%
C541 PXL439670-1040 0.1uF 50V +80% -20%
C542 PME039550-1000 10 uF 25V 20% 5x11mm
C544 PXL456470-3310 330pF 50V 10%
C545 PXL456470-3310 330pF 50V 10%
C546 PXL439670-1030 ;0.01 uF 50V +80-20%
C549 PRE039540-4710 470uF 16V 20% D8xL11mm
C55 PXL410370-4710 470 pF 50V 5%
C550 PXL439670-1040 0.1uF 50V +80% -20%
C551 PVE039550-1020 1000uF 25V 20% 85`C 10x17
C552 PVE039550-1020 1000uF 25V 20% 85`C 10x17
C553 PXL439670-1040 0.1uF 50V +80% -20%
C554 PME039540-4700 47 uF16V20%SIZE=5x11mm
C555 PXL456470-2210 220pF 50V 10%
C556 PXL456470-2210 220pF 50V 10%
C557 PXL439670-1040 0.1uF 50V +80% -20%
C56 PXL439670-1030 ;0.01 uF 50V +80-20%
C57 PME039550-1000 10 uF 25V 20% 5x11mm
C58 PXL456470-1520 0.0015 uF 50V 10%
C59 PXL410370-4710 470 pF 50V 5%
C6 PBE039542-1011 CHIP VER 100 uF 16V 20%
C60 PXL439670-1040 0.1uF 50V +80% -20%
C61 PME039550-1000 10 uF 25V 20% 5x11mm
C62 PXL439670-1040 0.1uF 50V +80% -20%
C63 PME039550-1000 10 uF 25V 20% 5x11mm
C64 PXL439670-1040 0.1uF 50V +80% -20%
C65 PME039550-1000 10 uF 25V 20% 5x11mm
C66 PXL456470-1520 0.0015 uF 50V 10%
