21
MAIN BOARD PARTS LIST
CAPACITOR
C67 PXL410370-4710 470 pF 50V 5%
C68 PXL439670-1040 0.1uF 50V +80% -20%
C69 PBE039542-4700 CHIP VER 47 uF 16V 20%
C7 PXL439670-1040 0.1uF 50V +80% -20%
C70 PBE039542-2201 22 uF 16V 20% 85'C
C71 PME039550-1000 10 uF 25V 20% 5x11mm
C72 PXL456470-1520 0.0015 uF 50V 10%
C73 PXL410370-4710 470 pF 50V 5%
C74 PME039550-1000 10 uF 25V 20% 5x11mm
C75 PXL456470-1520 0.0015 uF 50V 10%
C76 PXL410370-4710 470 pF 50V 5%
C77 PME039550-1000 10 uF 25V 20% 5x11mm
C78 PXL456470-1520 0.0015 uF 50V 10%
C79 PXL410370-4710 470 pF 50V 5%
C8 PVE039550-1020 1000uF 25V 20% 85`C 10x17
C80 PME039540-1010 100uF16V20%SIZE=5x11mm
C81 PXL439640-3340 0.33 uF 16V +80-20%
C81 PXL439670-3340 0.33 uF 50V +80-20%
C82 PME039540-1010 100uF16V20%SIZE=5x11mm
C83 PXL439670-1040 0.1uF 50V +80% -20%
C84 PBE039542-1011 CHIP VER 100 uF 16V 20%
C85 PXL439670-1040 0.1uF 50V +80% -20%
C86 PXL439670-1040 0.1uF 50V +80% -20%
C87 PBE039542-2201 22 uF 16V 20% 85'C
C88 PME039550-1000 10 uF 25V 20% 5x11mm
C89 PXL456470-1520 0.0015 uF 50V 10%
C90 PXL410370-4710 470 pF 50V 5%
C91 PME039550-1000 10 uF 25V 20% 5x11mm
C92 PXL456470-1520 0.0015 uF 50V 10%
C93 PXL410370-4710 470 pF 50V 5%
C94 PXL439670-1040 0.1uF 50V +80% -20%
C95 PXL439670-1040 0.1uF 50V +80% -20%
C96 PXL456470-1020 0.001 uF 50V 10%
C97 PYL439630-1060 10uF 10V +80-20%
C98 PXL439670-1040 0.1uF 50V +80% -20%
C99 PXL439670-1040 0.1uF 50V +80% -20%
INTERGRATED CIRCUIT
D1 RCZ005006-0011 CHIP ZENER 5.6V 5% 0.5W
D10 RCD114148-0010 DIODE SW 1N4148 SMT
D11 RCD114148-0010 DIODE SW 1N4148 SMT
D12 RCD114148-0010 DIODE SW 1N4148 SMT
D13 RCD114148-0010 DIODE SW 1N4148 SMT
D14 RCD114148-0010 DIODE SW 1N4148 SMT
D15 RCD155062-0010 BZV55-C6V2 SOD80C PHILIP
S
D16 RCD100034-0030 SR34 SMB/DO-214AA
D17 RCD114148-0010 DIODE SW 1N4148 SMT
D18 RCD114148-0010 DIODE SW 1N4148 SMT
D19 RCD155062-0010 BZV55-C6V2 SOD80C PHILIP
S
INTERGRATED CIRCUIT
D20 RCZ005010-0010 10V 5% 0.5W (F5)SOD-123
D21 RCD100034-0030 SR34 SMB/DO-214AA
D22 QCL085010-0000 CHIP RES. 0 OHM JUMP WIR
E
D25 RCD100004-0001 1A 100V TYPE
D4 RCZ005006-0011 5.6V 5% 0.5W
D8 RCZ005033-Z010 33V 5% 0.5W (M2)
D9 RCD114148-0010 DIODE SW 1N4148 SMT
Q10 RCN003904-0005 XISTR NPN PMBT3904 SOT23
Q10 RCN003904-0006 XISTR NPN MMBT3904-7-F
Q13 RCN003904-0005 XISTR NPN PMBT3904 SOT23
Q13 RCN003904-0006 XISTR NPN MMBT3904-7-F
Q14 RCP003906-0002 XISTR PNP 3906 SOT23
Q14 RCP003906-0003 XISTR PNP MMBT3906-7-F
Q20 RCN003904-0005 XISTR NPN PMBT3904 SOT23
Q20 RCN003904-0006 XISTR NPN MMBT3904-7-F
Q21 RCN003904-0005 XISTR NPN PMBT3904 SOT23
Q21 RCN003904-0006 XISTR NPN MMBT3904-7-F
Q22 RCN203326-0001 XISTR NPN 2SC3326-A(TE85L
)
Q23 RCN003904-0005 XISTR NPN PMBT3904 SOT23
Q23 RCN003904-0006 XISTR NPN MMBT3904-7-F
Q24 RCN003904-0005 XISTR NPN PMBT3904 SOT23
Q24 RCN003904-0006 XISTR NPN MMBT3904-7-F
Q25 RCN203326-0001 XISTR NPN 2SC3326-A(TE85L
)
Q26 RCN003904-0005 XISTR NPN PMBT3904 SOT23
Q26 RCN003904-0006 XISTR NPN MMBT3904-7-F
Q27 RCM002300-0001 MOSFET N-CH APM2300AAC
T
Q29 RCN203326-0001 XISTR NPN 2SC3326-A(TE85L
)
Q30 RCP003906-0002 XISTR PNP 3906 SOT23
Q30 RCP003906-0003 XISTR PNP MMBT3906-7-F
Q31 RCN203326-0001 XISTR NPN 2SC3326-A(TE85L
)
Q33 RCN203326-0001 XISTR NPN 2SC3326-A(TE85L
)
Q34 RCN203326-0001 XISTR NPN 2SC3326-A(TE85L
)
Q35 RCM002300-0001 MOSFET N-CH APM2300AAC
T
Q36 RCN003904-0005 XISTR NPN PMBT3904 SOT23
Q36 RCN003904-0006 XISTR NPN MMBT3904-7-F
Q37 RCN003904-0005 XISTR NPN PMBT3904 SOT23
Q37 RCN003904-0006 XISTR NPN MMBT3904-7-F
Q4 RCM002300-0001 MOSFET N-CH APM2300AAC
T
Q5 RCN003904-0005 XISTR NPN PMBT3904 SOT23
Q5 RCN003904-0006 XISTR NPN MMBT3904-7-F
Q6 RCM002300-0001 MOSFET N-CH APM2300AAC
T
Q7 RCN003904-0005 XISTR NPN PMBT3904 SOT23
Q7 RCN003904-0006 XISTR NPN MMBT3904-7-F
TD1 RCD100034-0030 SR34 SMB/DO-214AA
TD3 RCD100034-0030 SR34 SMB/DO-214AA
U1 RCI257600-0001 5P 5V SIMPLE SWIT REG
U1 RCI257600-0003 5P LM2576D2TR4-005 D2PAK
U10 RCI290040-0000 32P A29L040L-70 PLCC AMIC
U10 RCI290040-B000 32P EN29LV040A-70JCP
