MAIN BOARD PARTS LIST
INTERGRATED CIRCUIT
U10 RCI390020-A001 IC32P SST39VF020-70PLCC
U12 RCI111718-0002 3 PIN NCP1117ST18T3 1.8V
U13 RCI007808-0002 3 PIN 78D08A 8V 1A TO252 U
T
U14 RCI111733-0002 3 PIN NCP1117ST33T3 3.3V
U15 RCI000015-0001 128P MTL015 PQFP MYSON
U16 RCI111733-0002 3 PIN NCP1117ST33T3 3.3V
U17 RCI111725-0002 3 PIN NCP1117 2.5V SOT223
U19 RCI007805-0005 3P GU7805 TO-263 GTM 5V 1
A
U2 RCI001084-0002 3P AP1084KLA ADJ TO263
U20 RCI140692-0001 14PMC14069UBDR2SOONHE
X
U21 RCI003541-0001 8 PIN APA3541 SOP-8
U22 RCI744052-0002 16 PIN 74HC4052D SO16
U23 RCI001729-0001 6P NCP1729SN35T1 TSOP O
N
U24 RCI008954-0001 44P CS8954GV PLCC MYSON
U25 RCI111733-0002 3 PIN NCP1117ST33T3 3.3V
U26 RCI009720-0001 8P MP9720DS SOMPS 20W
U27 RCI009720-0001 8P MP9720DS SOMPS 20W
U28 RCI004558-1001 8P JRC4558M JRC OP AMP
U31 RCI001500-0001 5P KP1500-50S5 TO263-5L KT
C
U31 RCI002596-0001 5P LM2596S-5.0 TO-263
U5 RCI111733-0002 3 PIN NCP1117ST33T3 3.3V
U6 RCI811030-0002 3P STL8110GCL300 SOT23
U7 RCI490003-0001 144P VCT49X3RXM PMQFP
CHIP BEAD
FB1 SCB008051-3000 30O 25% AT 100MHZ IDC3000
m
FB10 SCB008051-3000 30O 25% AT 100MHZ IDC3000
m
FB11 SCB008051-3010 300 OHM 25% 100 MHz 2A 08
0
FB12 SCB008051-3010 300 OHM 25% 100 MHz 2A 08
0
FB13 SCB008051-3000 30O 25% AT 100MHZ IDC3000
m
FB14 SCB008051-3000 30O 25% AT 100MHZ IDC3000
m
FB15 SCB008051-3010 300 OHM 25% 100 MHz 2A 08
0
FB16 SCB008051-3010 300 OHM 25% 100 MHz 2A 08
0
FB17 SCB008051-3000 30O 25% AT 100MHZ IDC3000
m
FB19 SCB008051-3000 30O 25% AT 100MHZ IDC3000
m
FB2 SCB008051-3000 30O 25% AT 100MHZ IDC3000
m
FB21 SCB008051-3000 30O 25% AT 100MHZ IDC3000
m
FB25 SCB008051-3000 30O 25% AT 100MHZ IDC3000
m
FB3 SCB008051-3000 30O 25% AT 100MHZ IDC3000
m
FB5 SCB008051-3010 300 OHM 25% 100 MHz 2A 08
0
FB6 SCB008051-3010 300 OHM 25% 100 MHz 2A 08
0
FB7 SCB008051-3000 30O 25% AT 100MHZ IDC3000
m
FB8 SCB008051-3000 30O 25% AT 100MHZ IDC3000
m
FB9 SCB008051-3000 30O 25% AT 100MHZ IDC3000
m
L10 SCB008051-3010 300 OHM 25% 100 MHz 2A 08
0
L11 SCB008051-3010 300 OHM 25% 100 MHz 2A 08
0
L12 SCB008051-3010 300 OHM 25% 100 MHz 2A 08
0
L13 SCB008051-3010 300 OHM 25% 100 MHz 2A 08
0
L14 SCB008051-3010 300 OHM 25% 100 MHz 2A 08
0
CHIP BEAD
L15 SCB008051-3000 30O 25% AT 100MHZ IDC3000
m
L16 SCB008051-3010 300 OHM 25% 100 MHz 2A 08
0
L17 SCB008051-3010 300 OHM 25% 100 MHz 2A 08
0
L29 SCB012061-1210 120 OHM 25% 100 MHz 3A 12
0
L30 SCB012061-1210 120 OHM 25% 100 MHz 3A 12
0
L7 SCB008051-3010 300 OHM 25% 100 MHz 2A 08
0
L8 SCB008051-3010 300 OHM 25% 100 MHz 2A 08
0
L9 SCB008051-3010 300 OHM 25% 100 MHz 2A 08
0
MISCELLANEOUS
FB18 SCN011714-1000 INDUCTOR 10uH 20% 4.5A
FB20 SCN011714-1000 INDUCTOR 10uH 20% 4.5A
FB22 SIL002028-0010 TOROID COIL 30uH LI-YOU
FB23 SIL002028-0010 TOROID COIL 30uH LI-YOU
F1 KCS010002-0080 CHIP FUSE 5A 125V SLOW
J1 CCN250000-0112 CONNECTOR B12B-XH-A
J11 CCN200000-0106 CONNECTOR 6 PIN P=2.0mm
J12 CCN200000-0103 CONNECTOR 3 PIN P=2.0mm
J13 CJM036013-1020 PHONE JACK D3.6 7P L15+3
J16 CJR004305-0040 RCA JACK 4P W-RED/W-RED
J17 CCN250000-0102 CONNECTOR B2B-XH-A 2 PI
N
J19 CCN250000-0102 CONNECTOR B2B-XH-A 2 PI
N
J2 CCN250000-0107 CONNECTOR B7B-XH-A 7 PI
N
J3 CCN200000-0108 CONNECTOR 8 PIN P=2.0mm
J5 CCN200000-0109 CONNECTOR 9 PIN P=2.0mm
J7 CCN125050-0110 CONNECTOR 10P P1.25xH4.7
J9 CJR006303-0040 RCA JACK 6P G-B-R/Y-W-R
JTTL1 CHC050100-0150 CHIP FPC CON 50PIN P0.5xH
2
L18 SCN023600-3A30 CHIP INDUCTORS 3.3uH 0805
L19 SCN023600-3A30 CHIP INDUCTORS 3.3uH 0805
L2 SIL002026-0010 TOROID COIL 70uH 2.3A 20%
L20 SCN023600-3A30 CHIP INDUCTORS 3.3uH 0805
L21 SCN026601-3390 INDUCTOR 3.3 UH 10%1210
L22 SCN026601-3390 INDUCTOR 3.3 UH 10%1210
L23 SCN026601-3390 INDUCTOR 3.3 UH 10%1210
L24 SCN026601-3390 INDUCTOR 3.3 UH 10%1210
L25 SCN026601-1000 CHIP INDUC10uH10% 150mA
L28 SCN026601-1000 CHIP INDUC10uH10% 150mA
L31 SIL002026-0010 TOROID COIL 70uH 2.3A 20%
P1 CJC010007-3010 RCA+DIN JK 1RCA+4P DIN 9P
U18 WTP000025-0001 TUNER LG:TAEM-G589F-F
U8 JFT007001-0010 BANDPASS FILTER 5P X6966
M
U9 RCI240016-0004 8P AT24C16AN-10SU-2.7
Y1 JQC053000-2061 CRYSTAL 20.250MHZ AT-49
Y2 JCQ112000-1461 CRYSTAL 14.31818MHZ HC
Y2 JCQ313000-1461 CHIP CRYST 14.31818 MHZ
Y3 JCQ112000-1461 CRYSTAL 14.31818MHZ HC
Y3 JCQ313000-1461 CHIP CRYST 14.31818 MHZ
