22
20 RXE0+ RXE0+
21 RXE1- RXE1-
22 RXE1+ RXE1+
23 RXE2- RXE2-
24 RXE2+ RXE2+
25 GND Ground
26 GND Ground
27 RXEC- RXEC-
28 EXEC+ EXEC+
29 RXE3- RXE3-
30 RXE3+ RXE3+
J3(6pin/2.0mm)：HDCP CONNECTOR(NC)
NO Definition Description
1 +12V +12V DC Power Supply
2 +5V +5V DC Power Supply
3 GND Ground
4 SCL IIC SCL
5 SDA IIC SDA
6 GND Ground
J4 (14pin/2.0mm): KEY/Remote control&Indicator light port
NO Definition Description
1 GND Ground
2 K7 EXIT key
3 K6 POWER key
4 K5 RIGHT key
5 K4 LEFT key
6 K3 SOURCE key
7 K2 UP key
8 K1 DOWEN key
9 K0 MENU key
10 GND Ground
11 IR Remote receive
12 LED_G Green indicator
13 LED_R Red indicator
14 LED_5V +5V power
J5 (6pin/2.0mm):BUILT_IN POWER SUPPLE
NO. Definition DESCRIPTION
1 ON/OFF Power On/Off
2 5VSTB +5V DC Power Supply when Standby
3 GND Ground
