Akai MPC Service Manual

D374,402~416
3 EC10616TS Capacitor Electrolytic 10uF/16V 4*5mm 2 C19,20
3
EC22616TS Capacitor Electrolytic 22uF/16V 5*5mm 2 C4,5
3 EC47616TS Capacitor Electrolytic 47uF/16V 5*5mm 12 C97,120,125~128,132,133,137,139,170,172
3
FCN1T1002602
FCN Down Touch ZIF SMD Pitch=1.0mm
26P
1 J25
3 FCN2R1001001 FCN Dual Touch SMD Pitch=1.0mm 10P 1 J11
3
IC74HC253DR IC 74HC253DR SOIC-16 2 U12,15
3 IC74HC595 Integrated Circuit 12 U7,9,10,11,14,21,23~26,29,30
3
IC74LVC139AD IC74LVC139AD SOP-16 1 U27
3
ICYH100M03 IC(ICSTM32F103RCT6+program)TQFP-64 1 U4
4
ICSTM32F103RCT6 IC STM32F103RCT6 LQFP-64 1 (U4)
3
ICYH100M04 IC(ICLCMXO640C+Program)TQFP-100 1 U3
4
ICLCMXO640C IC LCMXO640C-3TN100C 1 (U3)
3
ICYH100M05 IC(ICPIC16F722AISS+Program)SSOP-28 1 U8
4
ICPIC16F722AISS IC PIC16F722A-I/SS SSOP-28 1 (U8)
3
LDH0606AV2G7008 Liquid-
emitting Diode Red/Green SMD 0603
16 LED2,11~19,23~26,28,29
140°
3
LDKPT-1608CGCK
Liquid-emitting Diode Green SMD 0603
angle 1 D394
120°
3
LDKPT-1608SURCK Liquid-emitting Diode Red SMD 0603 angle 271 D1~36,46~69,79~122,132~147,178~229
120° D239~276,282~313,315~322,362~367
D387~393,395~401,LED27
3
LDKPT-1608SYCK
Liquid-emitting Diode Yellow SMD 0603
angle 15 D277,D278,LED1,3~10,20~22,276
120°
3
MT1504438 Encoder Holder 1 (E1) 28
3
RS000008J05 RES 0Ω 5% SMD 0805 5 R9,86,87,379,380
3
RS000010J03 RES 0Ω 5% SMD 0603 15 R96,171,220,221,228~232,234,235
R238,243,244,245
3
RS000108J05 RES 1.0 Ω 5% SMD 0805 1 R85
3
RS001K10F03 RES 1K 1% SMD 0603 4 R205,206,207,286
3
RS001M10F03 RES 1M 1% SMD 0603 6 R10,15,84,89,219,242
3
RS002210F03 RES 22Ω 1% SMD 0603 2 R51,75
3
RS003910F03 RES 39Ω 1% SMD 0603 16 R38,49,74,90,101,113,115,117,127,129
R131,133,143,145,147,149
3
RS004710F03 RES 47Ω 1% SMD 0603 34 R2,3,6,43,44,95,102~105,109,125,158~160
R167,169,170,200,201~204,208,209,222
R223,224,233,318,320,365~367
3
RS008208F05 RES 82Ω 1% SMD 0805 30 R13,14,21~30,33~35,52~54,59~62,66~73
3
RS008210F03 RES 82Ω 1% SMD 0603 1 R139
3
RS010010F03 RES 100Ω 1% SMD 0603 6 R45,46,50,154,155,368
3
RS010K10F03 RES 10K 1% SMD 0603 49 R5,20,76~83,161,163,164,168,172,175,177
R179,181,183,185,187,189,191,193,195
R197,199,225,226,227,246,255,256,262
R265,268,270,272,276,278,281,282,284
R289,294,299,301,376
3
RS012010F03 RES 120Ω 1% SMD 0603 11 R92,110,174,211,213,236,240,248,252
R303,337
3
RS015010F03 RES 150Ω 1% SMD 0603 4 R141,142,151,325
3
RS01K510F03 RES 1.5K 1% SMD 0603 1 R47
3
RS022010F03 RES 220Ω 1% SMD 0603 26 R1,93,136~138,152,153,166,210,212,239
R241,251,253,304,336,338,339,340,341
R350~355
