Akai MPC Service Manual

3
RS024910F03 RES 249Ω 1% SMD 0603 1 R298
3
RS027010F03 RES 270Ω 1% SMD 0603 16 R48,65,88,99,108,114,116,118,128,130,132
R134,144,146,148,150
3
RS036K10F03 RES 36K 1% SMD 0603 1 R17
3
RS047010F03 RES 470Ω 1% SMD 0603 4 R237,249,283,293
3
RS047K10F03 RES 47K 1% SMD 0603 3 R4,16,41
3
RS04K708F05 RES 4.7K 1% SMD 0805 4 R247,257,285,378
3
RS068110F03 RES 681Ω 1% SMD 0603 2 R295,296
3
RS075K10F03 RES 75K 1% SMD 0603 2 R314,319
3
RS090910F03 RES 909Ω 1% SMD 0603 1 R297
3
RS100K10F03 RES 100K 1% SMD 0603 1 R250
3
RS1K6510F03 RES 1.65K 1% SMD 0603 4 R302,305~307
3
RS2K8710F03 RES 2.87K 1% SMD 0603 2 R287,288
3
RS301K10F03 RES 301K 1% SMD 0603 16 R94,162,165,173,176,178,180,182,184
R186,188,190,192,194,196,198
3
SC0306RINI SCREW M3X6 PPN 2 (E1)
3
SWEC12E24204A7 Switch Rotational Encode 24Pulse 17.5mm 1 E1
3
SWEVQ11L04M Switch Tact 4.3mm 160g Horizontal DIP 64 SW1~64
3
SWSKD22 Switch slide 2P2T 10MM 1 S14
3
TE622001201 Pin Header 90° Pitch:2.00mm Single Row 1 J3
12P DIP
3
TE622001401 Connector 14P 1 J6
3
TE682000501 Pin Header 90° Pitch:2.0mm Single Row 5
2
J19,20
Pin SMD
3
TE962542001 Terminal 20P 2.54mm 1 J16
3
TR2SK1828 MOSFET N-CH 20V MAIN 2-Pin 16 Q52,53,71~84
3
VRR10301508 Potentiometer Rotary 10K2B*2 Shaft 1 P17
Length:22.5mm Dual-Unit
3
VRR10302205 Potentiometer Rotary 10K15A Shaft Length
1
P19
22.5mm Dual-Unit
3
VRR10402204 Potentiometer Rotary 100K2B Shaft Length 1 P18
22.5mm Dual-Unit
3
XTM01000X8 Crystal Oscillator 1.000MHz SO3225 SMD 1 U33
3
XTM08000X6F1 Crystal 8MHZ 49US SMD Fundamental 1 X1
2
TWPC11A002B01 LCD Adapter PCB Assembly 1
3
CS102K5003X7R CCAP SMD 1nF/50V 10% 0603 X7R 2 C103,104
3
CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 10 C102,CC01~CC09
3
CS105K1603X7R CCAP SMD 1uF/16V 10% 0603 X7R 4 C96,98,100,101
3
FCN1T0502601
FCN Down Touch ZIF SMD Pitch:0.5mm
26P 1 J17
3 FCN2R1001001 FCN Dual Touch SMD Pitch=1.0mm 10P 1
J18
3
LCM-OD3696AXEWN LCM OD3696AXEWN 6 O'CLOCK 1 LCM1
3
MT1504439 COG Holder 1 (LCM1)
3
RS000010J03 RES 0Ω 5% SMD 0603 2 R274,275
1 TWPC11A00301 REAR ANALOG PCB Assembly 1
2
AA822748X Diode BAV99 8 D1~4,10,11,14,15
2
AL1-07-0102 Capacitor Electrolytic 1000uF/6.3V 2 C85,86
8*12mm
2
AL1-12-0472 Capacitor Electrolytic 47uF/63V 6.3*11m 9 C22,37,38,39,40,132,133,134,135
2
AL2-51-4401 Transistor 2N4401 NPN SOT-23 (Transisto 8 Q5,6,8,12~14,19,20
MMBT4401LT1 NPN SOT-23)
2
AL2-51-4403 Transistor 2N4403 PNP SOT-23 1 Q16
2
AL2-54-0856 Transistor BC856 PNP SOT-23 4 Q7,9,10,11
