Akai MPC Service Manual

2
RS010K10F03 RES 10K 1% SMD 0603 12 R30,31,40,48,91,93,103,136,167,260,262,263
2
RS015K10F03 RES 15K 1% SMD 0603 8 R13~17,34~36
2
RS01K310F03 RES 1.3K 1% SMD 0603 12 R42,68,85,89,96,118,122,129,130,141,142,147
2
RS01K408F05 RES 1.4K 1% SMD 0805 6 R70,73,79,82,120,135
2
RS022008F05 RES 220Ω 1% SMD 0805 8 R71,72,74,80,81,83,84,90
2
RS022010F03 RES 220Ω 1% SMD 0603 2 R27,37
2 RS027408F05 RES 274Ω 1% SMD 0805 2
R171,172
2 RS047010F03 RES 470Ω 1% SMD 0603 3
R28,38,259
2 RS04K710F03 RES 4.7K 1% SMD 0603 1
R261
2 RS056208F05 RES 562Ω 1% SMD 0805 2
R5,8
2 RS100K08F05 RES 100K 1% SMD 0805 2
R29,39
2 RS100K10F03 RES 100K 1% SMD 0603 8
R18,21,32,33,41,53,92,108
2 RS2K4310F03 RES 2K43 1/10W SMD 1% 0603 2
R57,58
2 RS2K5510F03 RES 2.55K 1% SMD 0603 24
R45,46,56,63,69,86~88,97,100,106,117,123
R125~127,131,133,134,140,143~146
2 RS3K0108F05 RES 3.01K 1% SMD 0805 2
R119,121
2 RS47K510F03 RES 47.5K 1% SMD 0603 13
R2,3,59,60,61,62,102,115,116,157~160
2 RS510K08F05 RES 510K 1% SMD 0805 1
R47
2 RS56K208F05 RES 56.2K 1% SMD 0805 2
R6,7
2 RS5K3610F03 RES 5.36K 1% SMD 0603 12
R10,11,23~26,52,55,95,101,104,105
2 RS681K08F05 RES 681K 1% SMD 0805 2
R19,20
2 RS6K1910F03 RES 6.19K 1% SMD 0603 2
R51,54
2 RS8K6610F03 RES 8K66±1% SMD 0603 1
R124
2 SWDS-11L-C2 Switch Slide 2P2T 3
S1,2,3
2 TE611500101 Connector 1
J18
2 TE612001201 Pin Header 180° Pitch:2.00mm Single Row 1
J5
12P DIP
2 TE612001401 Connector Base 14P 180° 1
J12
2 TR2SD2114KSM Transistor 2SD2114K NPN SOT-23 6
Q1~4,15,17
2 UHFS4W1010-331K Capacitor 330UH 1
L2
2 UHPIC1207-221M Inductor SMD 220UH 1
L6
2 UHPID1207-102M
Inductor 1000UH 0.613A 20% 12*12*8MM
SMD
1
L5
1 TWPC11A00401 REAR DIGITAL PCB Assembly 1
32
2 AA822528X IC SN74HCU04PW 1
U13
2 AL1-08-0222 Capacitor Electrolytic 22uF/16V 4*7mm 1
C35
2 AL1-60-2222 Ecap Low Esr 22UF/16V SMD-B 2
C25,66
2 AL2-61-0431 REG LM431 2.5V-37V 100MA 2% SOT-23 1
U1
2 AL4-21-5000
FCN Down Touch ZIF SMD Pitch=0.5mm
50P
1
J6
2 AL7-60-0003
Crystal 24.576MHZ 49US SMD
Fundamental
1
X3
2 CS100J5003NPO CCAP SMD 10pF/50V 5% 0603 NPO 1
C61
2 CS102J5003NPO CCAP SMD 1nF/50V 5% 0603 NPO 4
C13,48~50
2 CS102K5003X7R CCAP SMD 1nF/50V 10% 0603 X7R 4
C45,54,84,86
2 CS103K2502X7R CCAP SMD 0.01UF/25V 10% 0402 X7R 2
C2,3
2 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 2
C1,4
2 CS104K2502X5R CCAP SMD 0.1UF/25V 10% 0402 X5R 16
C37,42,58~60,65,69,73,74,81,83,87
C88,99,103,105
2 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 35
C5~7,9,12,15~20,22,23,28~30,33,38~40
C43,53,63,64,78,79,82,85,89,91,97,100
C104,108,109
2 CS105K1603X7R CCAP SMD 1uF/16V 10% 0603 X7R 2
C8,14
2 CS106K0605X5R CCAP SMD 10uF/6.3V 10% 0805 X5R 4
C21,36,56,80
