Akai MPC Service Manual

2 CS180J5003NPO CCAP SMD 18pF/50V 5% 0603 NPO 2
C31,32
2 CS220J5003NPO CCAP SMD 22pF/50V 5% 0603 NPO 2
C46,47
2 CS225K1605X7R CCAP SMD 2.2uF/16V 10% 0805 X7R 1
C41
2 CS330J5003NPO CCAP SMD 33pF/50V 5% 0603 NPO 6
C93~95,98,101,102
2 CS333K2502X7R CCAP SMD 0.033UF/25V 10% 0402 X7R 7
C52,70,110~114
2 CS471J5003NPO CCAP SMD 470pF/50V 5% 0603 NPO 6
C67,71,72,75~77
2 CS475K0603X5R CCAP SMD 4.7uF/6.3V 10% 0603 X5R 3
C55,57,62
2 CS475K1605X5R CCAP SMD 4.7uF/16V 10% 0805 X5R 3
C24,26,27
2 DISDMBRA340T3G
Shottky diode DISDMBRA340T3G SMD 3A
40V
3
D4,5,8
2 DIZDP6SMB16CAE3 Transient Voltage Suppressor Diode 1
D9
P6SMB16CA-E3 SMB
2 EC33725TLE Capacitor Electrolytic low ESR 330uF/25V 1
C10
8*12mm
2 EC47616TS Capacitor Electrolytic 47uF/16V 5*5mm 2
C106,107
2 EC47725TLE Capactor Electolytic LOW-ESR 470UF/25V 3
C34,68,96
5X10X13mm
2 ECS47606B Capacitor Electrolytic 47uF/6V B type SMD 3
C44,51,92
2 FCN1T1002602
FCN Down Touch ZIF SMD Pitch=1.0mm
26P
1
J10
2 IC74HC4040PWR IC 74HC4040PWR TSSOP-16 1
U11
2 IC74HC4053PWR IC 74HC4053PWR TSSOP-16 1
U12
2 ICAK4589VQ IC AK4589VQ LQFP-80 1
U8
2 ICAP1510SL-13 IC Pwm Control 3A Step-Down Converter 2
U7,10
AP1510SL-13 SOP-8L
2 ICLM393DR IC OPA LM393DR SOIC-8 1
U2
2 ICMC33078DR2G I.C. 1
U14
2 ICSN74AHCT1G126 IC SN74AHCT1G126DBVR TSSOP-5 1
U5
2 ICTPS2560DRCR IC TPS2560DRCR SON-10 1
U6
2 ICUPD720114GA IC USB 2.0 HUB Controller UPD720114GA 1
U4
TQFP-48
2 ICUSBLC62SC6 IC USBLC62SC6 SOT-23-6L 3
D1~3
2 ICYH100M06 IC(ICAT32UC3A364+Program)TQFP-144 1
U9
2 ICAT32UC3A364 IC AT32UC3A364 TQFP-144 1
(U9)
2 JK0894858000 A TYPE USB JACK 4P 90° PIN 2
J1,2
2 JK0USBR-BSFO-TH B-Type USB Jack 90 °(Orange) 1
J3
2 JK4KRJ2043B6311 RCA JACK 6P 90° PIN Black/Black 1
J4
2 JKDJ-0702B-020 DC Base 2.0MM 1
J5
2 OTYIN11138 Pulse Transformer ER9.5 Vertical SMD 1
T1
8Pin 1:1
2 PC11A004 REAR DIGITAL PCB 4Layer FR-4 1.6T 1
-
135*105MM
2 RS000004J06 RES 0Ω 5% SMD 1206 2
R1,5
2 RS000008J05 RES 0Ω 5% SMD 0805 5
R4,21,56,119,120
2 RS000010J03 RES 0Ω 5% SMD 0603 10
R14,44,60,104~106,115~118
2 RS001K10F03 RES 1K 1% SMD 0603 2
R59,65
2 RS001M10F03 RES 1M 1% SMD 0603 4
R2,32,100,102
2 RS002210F03 RES 22Ω 1% SMD 0603 2
R101,108
2 RS003310F03 RES 33Ω 1% SMD 0603 1
R111
2 RS003910F03 RES 39Ω 1% SMD 0603 2
R34,39
2 RS004710F03 RES 47Ω 1% SMD 0603 20
R24,26,28,33,35,47,49,81~85,91~94,99
R107,109,110
2 RS007508F05 RES 75Ω 1% SMD 0805 1
R3
2 RS010010F03 RES 100Ω 1% SMD 0603 16
R20,37,38,42,43,45,68,70,79,86,89
