Akai MPC Service Manual

R95~98,114
2 RS010K10F03 RES 10K 1% SMD 0603 6
R8,10,12,19,22,112
2 RS015K10F03 RES 15K 1% SMD 0603 1
R9
2 RS01K110F03 RES 1.1K 1% SMD 0603 4
R46,50,51,122
2 RS01K310F03 RES 1.3K 1% SMD 0603 2
R36,80
2 RS030010F03 RES 300Ω 1% SMD 0603 1
R23
2 RS033208F05 RES 332Ω 1% SMD 0805 1
R17
2 RS047K10F03 RES 47K 1% SMD 0603 2
R90,113
2 RS05R110F03 RES 5.1Ω 1% SMD 0603 1
R131
2 RS100K10F03 RES 100K 1% SMD 0603 4
R25,27,41,87
2 RS12K110F03 RES 12K1 1% SMD 0603 1
R13
2 RS16K910F03 RES 16.9K 1% SMD 0603 1
R6
2 RS2K4310F03 RES 2K43 1/10W SMD 1% 0603 3
R15,53,54
2 RS39K210F03 RES 39.2K 1% SMD 0603 1
R29
2 RS3K0110F03 RES 3K01 1/10W SMD 1/10W 0603 3
R18,48,88
2 RS3K8310F03 RES 3.83K 1% SMD 0603 4
R16,52,125,126
2 RS4K0210F03 RES 4K02 1% SMD 0603 1
R31
2 RS6K8110F03 RES 6.81K 1% SMD 0603 2
R40,78
2 SWSPUN19C606 Switch Push 2P2T Dual-Row Lock 1
SW1
2 TE10201002 Connector(10P Socket) 1
J9
2 TE612000402 Terminal(4P)180° 1
J8
2 TE962541001 10P Terminal 1
J7
2 UH100505T-601Y
BEAD 600Ω@100MHz 300mA 25% SMD
0402
25
L6,11~34
2 UH201209T-600Y BEAD 60Ω±25% 3A 0805 2
L5,7
2 UH201209T-601Y BEAD 600Ω @100MHz 2A ±25% 0805 1
L8
2 UHACM2012900-2P CHOKE 90Ω 0.4A 2.0X1.2mm 3
L1,2,4
2 UHSDRH12565150M Inductor (15uH/4.4A) 2
L9,10
2 UHSQD105T-751 Common Inductor 700Ω ±35% 10.3X8mm 1
L3
2 XTM12000X6 Crystal 12MHZ 49US SMD Fundamental 1
X2
2 XTM225792X6F1
Crystal 22.5792MHz 49US SMD
Fundamental
1
X4
2 XTM30000X6F1 Crystal 30MHZ 49US SMD Fundamental 1
X1
1 TWPC11A01201 Headphone Pcb Assembly 1
34
2 AA822748X Diode BAV99 2
D279,280
2 AL2-71-3079 IC MC33079 QUAD OP-AMP SOP-14 1
U17
2 CN0420005501 Flat Cable 4Pin Pitch:2.0mm Single Row 1
J13
Length:550mm Pin/Female
2 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 2
C161,163
2 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 11
C18,149,151,160,162,164,169,173~176
2 CS331J5003NPO CCAP SMD 330pF/50V 5% 0603 NPO 4
C105,107,131,134
2 DIBAW56 Switch Diode BAW56 SOT-23 1
D238
2 ECS47616D
Capacitor Electrolytic 47uF/16V D type
SMD
4
C145,146,150,152
2 FCN2R1001001 FCN Dual Touch SMD Pitch=1.0mm 10P 1
J8
2 ICNJM4580E IC NJM4580E SOIC-8 1
U16
2 JK3LJE3513A-3RT 3.5φ Phone Jack 3P 90° Female 1
J7
2 JK6L0670CBKA6A 6.4φ Phone JACK 7PIN 90° Female 3
J2,9,10
2 MT1504443 Fixed Holder 2
(R291,292) 59
2 PC11A012
Headphone PCB 2Layer FR-4 1.6T
127*56MM
1
-
2 RS001K10F03 RES 1K 1% SMD 0603 2
R371,373
2 RS001M10F03 RES 1M 1% SMD 0603 2
R258,266
2 RS002K10F03 RES 2K 1% SMD 0603 4
R216,217,218,254
2 RS006208F05 RES 62Ω 1% SMD 0805 2
R259,261
