Akai MPD32 Service Manual

Lvl Materials SPECS Qt
y
Part Location
.1 AA406633J PE BAG 370X280X.03 PRINTING 0.006
.1 AL7-51-0226 SAFETY INSTRUCTION 1.000
.1 AL9-15-0423 KNOB SLIDE (PRINTING) 8.000 2
..2 PT1510602 KNOB SLIDE 1.000
.1 AL9-30-0045 SILICON KEY PAD 1.000 6
.1 AL9-63-0005-C CD DISC (BFD LITE) 1.000
.1 AL9-63-0010 ABLETON LIVE LITE CD 1.000
.1 AL9-63-0011
CD-ROM SOFTWARE USER APPLICATION AD32
1.000
.1 BAGL-40A WIRE CLIP 2.000 40
.1 BAGL-70L WIRE CLIP 2.000 37
.1 CA040210002
CORD USB A-B L1000 BLACK + EMI COIL + USB 2.0 TAG
1.000
.1 CGAD32310AKA01 INNER CARTON 1.000
.1 CTAD32513AKA01 OUTER CARTON 0.500
.1 ET834 DOUBLE SIDE TAPE 1.000 41
.1 EVA1304408 SHIELD LCD EVA 2.000 27
.1 EVA1504407 EVA 1.000 24
.1 EVA1504408 EVA 1.000 23
.1 FFC1410003501 14P FLAT WIRE 350MM FFC 1.000 28
.1 FFC1610004301 16P FLAT WIRE 430MM- ROHS FFC 1.000 29
.1 FFC1810002001 18P FLAT WIRE 200MM FFC 1.000 30
.1 FFC2010003501 20P FLAT WIRE 350MM FFC 1.000 31
.1 GEAKA04 AD32 ABLETON CARD 1.000
.1 GEALE03 BFD LITE SOFTWARE INSTALLATION 1.000
.1 GEALE04 BFD-DEMO-POSTCARD 1.000
.1 LAC22AKA25 LABEL (SERIAL NO/BARCODE) 1.000 35
.1 LAC22AKA42 ABLETON SERIAL NO STICKER 1.000
.1 LAC52ALE01 LABEL (SAFETY) 1.000 34
.1 LAC67MAR195
ADHESIVE TAPE NITTO 500 (68MMX5MM)
2.000 25
.1 LAC67MAR196
ADHESIVE TAPE NITTO 500 (50MMX7MM)
2.000 26
.1 LAC67YAH261
LABEL (GREEN MARKING) 02~03 VERSION FOR ROHS
0.500
.1 LAP67YAH255 LABEL (RED MARKING) 1.000
.1 MT1504407 FIXED HOLDER (L) 1.000 21
.1 MT1504409 FIXED HOLDER (R) 1.000 22
.1 MT1504418 PAD HOLDER 1.000 8
.1 MT153030601 AD32 BOTTOM PLATE(SPRAY&PRINT) 1.000 16
..2 MT1530306 AD32 BOTTOM PLATE 1.000
.1 NM1501801 CONDUCTIVE COPPER FOIL TAPE 1.000 42
.1 OPAD32AKA02 QUICK START MANUAL 1.000
.1 OTM10030 SENSOR PAD 1.000 7
.1 PLAD3201 POLYFOAM(LEFT) 1.000
.1 PLAD3202 POLYFOAM(RIGHT) 1.000
.1 PT1110685 BUTTON SMALL 16.000 14
.1 PT1501404 LCD SCREEN 1.000 4
.1 PT1510604 BUTTON B (COOLGRAY 4C) 2.000 15
.1 PT1510612 BUTTON TRANSPORT (A) 1.000 12
.1 PT1510613 BUTTON TRANSPORT (B) 4.000 13
.1 PT1510620 KNOB 9.000 3
.1 PT1510621 KNOB COVER 9.000 33
.1 PT1510631 BUTTON SMALL(GRAY) 9.000 11
.1 PT153000701 TOP PANEL(SPRAY&PRINT) AD32 1.000 1
..2 PT1530007 TOP PANEL ( AD32 ) 1.000
.1 RU1330701 RUBBER FOOT 4.000 32
.1 SC0208RBBI SCREW 4.000 20
.1 SC0306RICI SCREW 3.000 19
.1 SC0308RBBI SCREW 11.000 17
.1 SC0308RBNI SCREW 29.000 39
.1 SC0308RIBI SCREW 8.000 18
.1 SD42050000 LAMIN BAG 420X500X0.5T 1.000
.1 TWLCM-WTDH00201 AD32 LCD ASS’Y 1.000 5
..2 CN0100000901 EARTH WIRE (9CM) 2.000
..2 LCM-WTDH002 LCD 1.000
MPD32 (BOM)

Akai MPD32 Specifications

General

Mixer section	-
Product color	Black
Drum pads backlight	Yes
Number of drum pads	16
Display type	LCD
USB connector type	USB Type-B
Power supply type	USB

Weight and Dimensions

Depth	384 mm
Width	308 mm
Height	64 mm
