Lvl Materials SPECS Qt
Part Location
.1 UHA8FS250120050 COIL FLAT 60 OHM 100MHZ 25X5MM 1.000 36
.1 AL9-79-0455 AD32 MAIN PCB ASSY 1.000 10
..2 SWSKQNAB
TACT SWITCH 4.3 (OLD PART:SWSKHVBB3420)
11.000 S1,2,3,4,5,6,7,8,9,10,11
..2 AL0-16-3402 CHIP RES. 34K 0805 1/10W 1% (SMD) 1.000 R35
..2 AL0-16-4751 RESISTOR 4.75K OHM 1% SMD 1.000 R26
..2 AL0-17-0101
CHIP RES.4X100 OHM 1/16W 5% C-C=0.8MM
6.000 R24,39,65,71,72,73
..2 AL0-17-0680
RES CHIP ARRAY 4X68 OHM 1/16W 5% ISOLATED C-C=0.8
2.000 R13,14
..2 AL2-51-0140
DIODE POWER SCHOTTKY MBRS140LT3 40V 1A
2.000 D28,29
..2 AL2-51-4401 TRANS NPN 2N4401 40V 1A SOT-23 6.000 Q6,7,8,9,11,14
..2 AL2-51-4403
TRANSISTOR PNP 2N4403 40V 800MA SOT-23
7.000 Q1,2,3,4,5,10,13
..2 AL2-52-5242 DIODE ZENER MMBZ5242B 12V SOT-23 2.000 D19,20
..2 AL2-54-6306
TRANS SMALL-SIGNAL DUAL EN-MOSFET FDC6306P SSOT-6
1.000 U10
..2 AL2-61-7223
IC REG VOLTAGE NJU7223DL1-33 3.3V TO-252
1.000 U12
..2 AL2-62-0004 IC 74AHC04 HEX INVERTERS SOP14 1.000 U7
..2 AL2-64-0154
IC 74HC154 4-TO-16 LINE DEC/DEMUX SOIC-24
1.000 U11
..2 AL2-71-1324 IC LMV324M SOT-14 2.000 U3,4
..2 AL2-73-4051
IC 74HC4051 SINGLE 8-CHAN MUX 16-PIN SOIC
1.000 U1
..2 AL2-74-0181
IC OPTO ISOLATOR TLP181 TRANS-OUT (SMD)
1.000 U13
..2 AL7-01-0060 CRYSTAL 40MHZ 3.3V SMD 1.000 U6
..2 AL9-40-0455 AD32 MAIN PCB 1.000
..2 AL9-61-0177 IC AL2-70-3433 PROGRAM BY PE 1.000 U5
...3 AL2-70-3433
IC MPU UPSD3433EV-40U6 8032 W/USB TQFP-80
1.000
..2 AL9-61-0178 IC AL2-69-2458 PROGRAM BY PE 1.000 U2
...3 AL2-69-2458
IC EEPROM SERIAL 256K-BIT 24C256 1MHZ SOIC-8
1.000
..2 CS102J5003COG CAP 1000PF NPO 0603 5% 50V 9.000 C17,44,46,49,69,83,84,85,87
..2 CS103K5003X7R C.CAP 0.010UF 50V X7R,±10% SMD 0603 7.000 C33,36,37,38,39 ,50,58
..2 CS104K5003X7R
CHIP CAP 0.1UF/50V,X7R,+/-10%, SMD 0603
51.000 C1,2,3,4,5,6,7,8,10,11,12,13,14,15,16,
C18,19,28,30,34,40,41,42,43,45,52,53,
C54,55,59,60,62,63,64,65,66,67,70,72,
C73
74
75
76
77
78
79
80
81
86
88
90
..2 CS105K1003X5R CERAMIC CAP 1UF 10V X5R 0603 3.000 C61,82,89
..2 CS220J5005COG C.CAP 22PF/50V/+-5% (0805 SMD) 2.000 C56,57
..2 CS561J5005COG CAP. 560PF NPO 4.000 C31,32,47,48
..2 DIBAV70
DIODE SWITCHING DUAL COMMON-CATHODE SOT-23
8.000 D9,10,11,12,13,14,16,17
..2 DIBAV99 SWITCHING DIODES, BAV99, SOT-23 18.000 D1,2,3,4,5,6,7,8,15,18,21,22,23,24,25,
D26,27,30
..2 DIZDSMAJ10ASM ZENER DIODE SMAJ10 SMA 1.000 D31
..2 ECS107M16SMD
E. CAPACITOR 100UF/16V SMD 6.3 X 5.3MM
1.000 C68
..2 ECS47525BP E.CAPACITOR 4.7UF/25V SMD-B 4.000 C29,35,51,71
..2 IC74AC574PW
IC 74AC574 OCTAL D-FF W/TRI-STATE OUTS TSSOP-20
2.000 U8,9
..2 RS00018J05 CHIP RES. 0 OHM,1/8W,+/-5%,0805 13.000 R11,12,33,48,49,75,85,86,96,101,106,
R111,117
..2 RS10018J05 CHIP RES. 10 OHM,1/8W,±5%,0805 1.000 R1
..2 RS10218J05 CHIP RES. 1K OHM,1/8W,±5%.0805 9.000 R74,76 ,79,80,82,87,89,90,95,
..2 RS10318J05 CHIP RES. 10K OHM,1/8W,±5%,0805 21.000 R15,16,17,18,29,30,32,54,55,61,63,66,
R70,84,93,94 ,99,104,105,107,108
..2 RS10418J05 CHIP RES. 100K OHM,1/8W,±5%,0805 8.000 R23,47,52,53,58, 67,68, 88
..2 RS10518J05 CHIP RES. 1M OHM,1/8W,±5%,0805 1.000 R10
..2 RS11218F05 RES 1.10K OHM 1/10W 1% 0805 1.000 R27
..2 RS12018J05 RES 12 OHM 1/10W 5% 0805 1.000 R81
..2 RS15218J05 CHIP RES. 1.5K OHM,1/8W,±5%,0805 1.000 R109
..2 RS22018J05 CHIP RES. 22 OHM,1/8W,±5%,0805 3.000 R40 ,59,60
..2 RS22118J05 CHIP RES. 220 OHM,1/8W,±5%,0805 5.000 R62,64,91,92,100
..2 RS243318F05 RES 24.3K OHM 1/10W 1% 0805 1.000 R25
..2 RS27318J05 CHIP RES. 27K OHM,1/8W,±5%,0805 4.000 R36,37,50,51
..2 RS332218F05 CHIP RES. 33.2K OHM, 1/8W, ±1%, 0805 1.000 R34
..2 RS33318J05 CHIP RES. 33K OHM,1/8W,±5%,0805 1.000 R69
..2 RS47018J05 CHIP RES. 47 OHM,1/8W,±5%,0805 2.000 R97,98
..2 RS47118J05 CHIP RES. 470 OHM,1/8W,±5%,0805 6.000 R41,42,43,45,46,83
..2 RS47218J05 CHIP RES. 4.7K OHM,1/8W,±5%,0805 6.000 R20,21,31,38,56,57
..2 RS47318J05 CHIP RES. 47K OHM,1/8W,±5%,0805 3.000 R102,103,110
..2 RS68018J05 CHIP RES. 68 OHM,1/8W,±5%,0805 1.000 R22
..2 RS75318F05 CHIP RESISTOR 75K(SMD)1% 0805 1.000 R19
