Akai MPD32 Service Manual

Lvl Materials SPECS Qt
y
Part Location
..2 RS82418J05 CHIP RES. 820K OHM,1/8W,±5%,0805 1.000 R77
..2 UHLPF3218MF100M INDUCTOR 10UH 1A 0.29O SMD-ROHS 2.000 L4,5
..2 UHZ2K102-RB-10
INDUCTOR BEAD 1000 OHM @ 100MHZ 200MA ±25% 0603
23.000 L1,2,6~13,15~27
..2 AA821842X SOCKET 20FMZ-ST 20P 1.000 J1
..2 AL0-09-0057 SLIDE VR (STEREO) 10KB 45MM 8.000 R2,3,4,5,6,7,8,9
..2 AL1-08-0222 E.CAP. 22UF 16V 20%(PANASONIC) 1.000 C9
..2 AL4-00-0002
JACK DIN 5 PIN MIDI PCB MOUNT 180°W/SHIELD SOCKET
2.000 J10,11
..2 AL4-02-0007 7P STEREO JACK 3.000 J12,13,14
..2 AL4-08-0402
CON USB SOCKET 4 PIN FEMALE PC-MNT HORIZONTAL
1.000 J15
..2 FCN1R1001401
CON SIL 14-PIN 1MM FFC/FPC 90° TOP-CONTACT
1.000 J3
..2 FCN1R1001601 16P CONNECTOR 2.000 J6,7
..2 FCN1R1001801 FPC CONNECTOR 18P 1.000 J2
..2 FCN1R1002003
CON SIL 20-PIN 1MM FFC/FPC 90° TOP-CONTACT
1.000 J4
..2 JKDJ-0702B-020 DC SOCKET 2.0MM 1.000 J9
..2 NM1106112 VELVET CARPET 8.000
(
R2,3,4,5,6,7,8,9
)
..2 PT1304702 INSULATOR SHEET 1.000
..2 TE10200502 5P CONNECTOR SOCKET 180° 1.000 J8
..2 TWAL3-02-008001 LED (AMBER) ASS’Y 9.000 LED1,2,3,4,5,6,7,8,9
...3 AL3-02-0080
LED AMBER CLEAR (NON-DIFFUSED) SUPER BRIGHT L-169X
1.000
...3 BALED2X2 LED PLASTIC BOSS (FLAT TYPE) 1.000
..2 TWLD103001 LED (YELLOW) ASS’Y 2.000 LED10,11
...3 BALE48208-5A PLASTIC BOSS (LED 8.5MM) 1.000
...3 LD1030 LED 3MM (YELLOW) 1.000
..2 WR112843032G1 5P CONNECTOR WIRE (USB) 430MM 1.000 J5
.1 AL9-79-0472 REAR PANEL PCB ASS'Y (AD32) 1.000 9
..2 SWSKQNAB
TACT SWITCH 4.3 (OLD PART:SWSKHVBB3420)
21.000 S1,2,3,4,5,6,7,8,9,10,11,12,13,14,15,
S16,17,18,19,20,21
..2 AL0-17-0680
RES CHIP ARRAY 4X68 OHM 1/16W 5% ISOLATED C-C=0.8
2.000 R3,4
..2 AL2-73-4051
IC 74HC4051 SINGLE 8-CHAN MUX 16-PIN SOIC
2.000 U1,2
..2 AL9-40-0472 AD32 FRONT REAR PCB 1.000
..2 CS102J5003COG CAP 1000PF NPO 0603 5% 50V 2.000 C26,31
..2 CS104K5003X7R
CHIP CAP 0.1UF/50V,X7R,+/-10%, SMD 0603
27.000 C6,7,8,9,14,15,16,17,18,19,20,21,22,
C23,24,25,27,28,29,30,32,33,38,39,40,
C41
,
46
..2 DIBAV99 SWITCHING DIODES, BAV99, SOT-23 22.000 D1,2,3,4,5,6,7,8,9,10,11,12,13,14,15,
D16,17,18,19,20,21,22
..2 RS00018J05 CHIP RES. 0 OHM,1/8W,+/-5%,0805 3.000 R9 ,21,22
..2 RS10018J05 CHIP RES. 10 OHM,1/8W,±5%,0805 1.000 R10
..2 RS10318J05 CHIP RES. 10K OHM,1/8W,±5%,0805 6.000 R1,2,5,6,7,8
..2 RS10518J05 CHIP RES. 1M OHM,1/8W,±5%,0805 2.000 R15,16
..2 UHZ2K102-RB-10
INDUCTOR BEAD 1000 OHM @ 100MHZ 200MA ±25% 0603
2.000 L1,2
..2 AL0-09-0044 VARIABLE RESISTOR 2.5KB 8.000 R1112,13,14,17,18,19,20
..2 AL1-08-0222 E.CAP. 22UF 16V 20%(PANASONIC) 1.000 C1
..2 AL6-00-0013 ENCODER 24-DETENT DC11B2421406 1.000 E1
..2 FCN1R1001401
CON SIL 14-PIN 1MM FFC/FPC 90° TOP-CONTACT
1.000 J2
..2 FCN1R1002003
CON SIL 20-PIN 1MM FFC/FPC 90° TOP-CONTACT
1.000 J1
..2 TWAL3-02-008001 LED (AMBER) ASS’Y 7.000 LED1,2,3,4,5,6,7
...3 AL3-02-0080
LED AMBER CLEAR (NON-DIFFUSED) SUPER BRIGHT L-169X
1.000
...3 BALED2X2 LED PLASTIC BOSS (FLAT TYPE) 1.000

Akai MPD32 Specifications

General

Mixer section	-
Product color	Black
Drum pads backlight	Yes
Number of drum pads	16
Display type	LCD
USB connector type	USB Type-B
Power supply type	USB

Weight and Dimensions

Depth	384 mm
Width	308 mm
Height	64 mm
