Akai MPK mini MK3 Service Manual

2 PLAD2002 POLY FOAM(R) 1
1 PT15106258 Stick(Black) 1
3
1 PT1510631404 Button(6)(Laser etched) 1
6
2 PT15106314 Knob 1
3 PMPA758 0.013
1 PT1510631504 Button(4)(Laser etched) 1
15
2 PT15106315 Knob 1
3 PMPA758 0.011
1 PT1510633801 Knob(Electroplated Bright Chrome ) 8
14
1 PT153007903 TOP Housing(PRINTING+PAINTING) 1
4
2 PT1530079 TOP Housing 1
3 PM-PA-707 ABS(PA-707) 0.141
3 PMP005-100 Powder 0.001
1 PT1530371 Bottom Housing(Black) 1
11
2 PM-757GJ08 Black Resin 0.238
1 RU1504408 Rubber(Black) 1
1
1 RU1510678 RUBBER PAD(CO-MOLD) 1
16
1 SC2310FBBI Screw M2.3*10 PFB Tapping 1
2
1 SC2608PBBI Screw 33
8
1 TWPC19A00801 Main PCB overall assembly 1
2 OTEO012832DWPP OLED 30*11.5*1.4mm 128*32 Dots white (No 1 (J1)
Distinguish)
2 PT15044129 OLED Holder 1 (J1)
2 TWPC19A00801T Main PCB SMT/AI overall assembly 1 -
3 PC19A008 Main PCB 2-Layer FR-4 306x75.2mm 1.6t 1 -
ENIG
3 TWPC19A008A01T Main PCB SMT/AI assembly 1 -
4 AA822748X Diode BAV99 1 D2
4 AL2-51-4401 Transistor 2N4401 NPN SOT-23 (Transistor 1 Q4
MMBT4401LT1 NPN SOT-23)
4 AL2-51-4403 Transistor 2N4403 PNP SOT-23 1 Q2
4 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 40 C55~C58,C60~C64,C66~C68,C71~C98
4 CS102K5003X7R CCAP SMD 1nF/50V 10% 0603 X7R 3 C13,C14,C15
4 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 3 C11,C12,C35
4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 18 C2,C4~C10,C24,C29~C33,C37,C44~C46
4 CS105K1603X5R CCAP SMD 1uF/16V 10% 0603 X5R 5 C3,C18,C21,C22,C23
4 CS180J5003NPO CCAP SMD 18pF/50V 5% 0603 NPO 2 C26,C28
4 CS225K1603X5R CCAP SMD 2.2uF/16V 10% 0603 X5R 2 C25,C27
4 CS471J5003NPO CCAP SMD 470pF/50V 5% 0603 NPO 3 C34,C50,C52
4 DIEN1N4148WSM HF Diode 1N4148 SOD123 SMD 11 D4~D14
4 DITVSNUP2201SM Transient Voltage Suppressol Diode 1 D1
1MR6 TSOP-6
4 ECS22616B Capacitor Electrolytic 22uF/16V B type 1 EC2
MD
4 ECS47606B ECAP 47uF/6.3V 4*5.3mm SMD 1 EC1
4 FCN1T0501502 FCN Down Touch ZIF SMD Pitch:0.5mm 15P 1 J1
4 FCN2T1001601 FCN Dual Touch 180° SMD Pitch:1.0mm 16P 1 FCN1
4 ICCD74HC4051PWR IC CD74HC4051PWR TSSOP-16 3 IC4,IC5,IC6
4 ICLMV321IDCKR IC LMV321IDCKR Operational Amplifiers 1 IC3
SOT-23-5
4 ICTLV75733PDBVR IC LDO TLV75733PDBVR SOT-23-5 1 IC1
4 ICU74HC595AGS16 IC U74HC595AG-S16-R SOP-16 3 IC7,IC8,IC9
4 ICYH108M07 IC(ICSTM32F070RBT6+Program) LQFP 1 IC2
5 ICSTM32F070RBT6 IC STM32F070RBT6 LQFP-64 1 (IC2)
4 LDB1911USD-20D Liquid-emitting Diode Red SMD 0603 angle 17 LD1~LD14,LD17~LD19
120°
4 LDRT-0606HR8GT Liquid-emitting Diode Red/Green SMD 0603 1 LD15

Akai MPK mini MK3 Specifications

General

Pad color	Black
Control type	Buttons, Rotary
Number of pads	8
Backlight buttons	Yes
MIDI-keyboard number of keys	25 keys
Sound effects	Synthesizer
Power source type	USB

Weight and Dimensions

Depth	181 mm
Width	318 mm
Height	44 mm
Weight	750 g
