Akai MPK mini MK3 Service Manual

4 RS000010J03 RES 0Ω 5% SMD 0603 8 R55~R61,R70
4 RS001K10F03 RES 1K 1% SMD 0603 3 R27,R32,R52
4 RS001M10F03 RES 1M 1% SMD 0603 2 R7,R25
4 RS004710F03 RES 47Ω 1% SMD 0603 3 R8,R9,R13
4 RS010010F03 RES 100Ω 1% SMD 0603 5 R20,R21,R22,R53,R54
4 RS010K10F03 RES 10K 1% SMD 0603 15 R10,R11,R12,R19,R23,R26,R30,R62~R69
4 RS012K10F03 RES 12K 1% SMD 0603 1 R29
4 RS022010F03 RES 220Ω 1% SMD 0603 8 R33~R37,R44~R46
4 RS047K10F03 RES 47K 1% SMD 0603 2 R17,R18
4 RS04K710F03 RES 4.7K 1% SMD 0603 1 R28
4 RS056010F03 RES 560Ω 1% SMD 0603 11 R38~R43,R47~R51
4 RS086610F03 RES 866Ω 1% SMD 0603 3 R1,R2,R4
4 RS100K10F03 RES 100K 1% SMD 0603 1 R31
4 RS392K10F03 RES 392K 1% SMD 0603 1 R24
4 RS47K510F03 RES 47.5K 1% SMD 0603 2 R5,R6
4 SWEVQPLHA15 Switch Tact Stem Height:1.5mm Operating 10 SW1~SW10
force 160gf Horizontal SMD
4 TRDMP3099L
MOSFET DMP3099L P-CHAN 30V 3.8A SOT-23
2 Q1,Q3
4 UH160808T-600Y BEAD 60Ω @100MHz 3A ±25% 0603 1 L1
4 UHACM2012900-2P Chock 90Ω 0.4A 2.0X1.2mm 1 L2
4 UHBLM18PG121SN1 Bead 120Ω ±25% 2A 0603 5 L3~L7
4 XTM08000X8 Crystal 8MHz S3225A SMD Fundamental 1 X1
3 TWPC19A008B01T Joysitck PCB SMT/AI assembly 1 -
4 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 2 C65,C69
4 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 2 C59,C70
2 TWPC19A008A01 Main PCB DIP assembly 1 18
3 AL4-08-0402 Con USB 4-Pin Female PC-MNT Horizontal 1 USB1
3 CN0420000705 Flat Cable Multicolored 4P Pitch 2.0mm 1 (TE2)
Dual Row Length 70mm Line/Line
3 JKK6J62AL6E2KY TRS Jack 7P 90° Female 1 J2
3 TE812000411 Terminal 1 TE2
3 VRR25201503 Potentiometer Rotary Volume 2.5KB Shaft 8 VR1~VR8
Length 15mm 360°
2 TWPC19A008B01 Joystick PCB DIP assembly 1 7
3 OT10K-N1B10K05N Pitch/MOD STICK VR 1 VR9
3 TE812000411 Terminal 1 TE3

Akai MPK mini MK3 Specifications

General

Pad color	Black
Control type	Buttons, Rotary
Number of pads	8
Backlight buttons	Yes
MIDI-keyboard number of keys	25 keys
Sound effects	Synthesizer
Power source type	USB

Weight and Dimensions

Depth	181 mm
Width	318 mm
Height	44 mm
Weight	750 g
