Akai MPK MINI Service Manual

BOM for AD07
ITEM Level P/N Description Q'ty MOQ
1 1 105-AD07-90 SHIPPING ASSY AD07 "ROHS" 1.00
2 632100100
BATTRERY 7# 1.5V "ROHS" 0.00 30K
3 NEW P/N Out carton FOR AD03 "ROHS" 0.10 5K
4 NEW P/N PLASTIC TOP COVER PS 0.7MM 305*280*33 MM FOR AD03 "ROHS" 1.00 5K
6 NEW P/N GIFT CARTON 350G 4C UV 365*280*70 MM FOR AD03 "ROHS" 1.00 5K
7 042232000 INSTRUCTION FOR AD03 "ROHS" 1.00 5K
8 NEW P/N LABLE1 FOR AD03 "ROHS" 1.00
9 NEW P/N LABLE2 FOR AD03 "ROHS" 1.00
10 NEW P/N LABLE3 70*50MM FOR AD03 "ROHS" 1.00
11 052232000 CLAPBOARD FOR AD03 "ROHS" 1.00
12 NEW P/N CD FOR AD07 "ROHS" 1.00
13 061184000 CABLE USB W/FERRITE 1 METER L=1500mm BLACK "HONGYUN" USBAM-MINI5P "ROHS" 1.00
14 105-AD07-70 SUB FINAL ASSY AD07 "ROHS" 1.00
15 020185000 FABRIC GASKET W=7mm FOR AD02 "ROHS" 2.00
16 021184200 KNOB ROTARY ABS FOR AD01 "ROHS" 8.00
17 021184400 BUTTON SQUARE 8-KEY SILICON RUBBER FOR AD01 "ROHS" 1.00
18 021184500 HIGH-RESISTANCE CARBON FILM PVC FOR AD01 "ROHS" 1.00
19 021184600 FOOT RUBBER BLACK FOR AD01 "ROHS" 4.00
20 021184700 KEY STROKE SILICON RUBBER 13-KEY "ROHS" 1.00
21 021185400 KEY ABS AS 7-KEY WHITE FOR AD02 "ROHS" 2.00
22 021185500 KEY ABS AS 5-KEY BLACK FOR AD02 "ROHS" 2.00
23 021185600 REAR KEY WHITE ABS FOR AD02 "ROHS" 1.00
24 021185700 KEY STROKE SILICON RUBBER 12-KEY "ROHS" 1.00
25 021243000 TOP COVER ABS FOR AD07 "ROHS" 1.00
26 021243100 BOTTOM COVER ABS FOR AD07 "ROHS" 1.00
27 021243200 BUTTON SQUARE 10-KEY SILICON RUBBER FOR AD07 "ROHS" 1.00
28 030185000 SHEET BRACKET METAL SHEET "ROHS" 1.00
29 054185000 FOAM GASKET 294*11*2mm FOR AD02 "ROHS" 1.00
30 061243000 CABLE FFC P=1mm 16PIN L=200mm CONTACT ON DIFFRENT SIDE "BINGCHUANG" 1.0*16P*200mm*A "ROHS" 1.00 1000
31 105-AD03-64 PCB ASSY KEYBOARD FOR AD03 "ROHS" 1.00
32 105-AD03-54 PCB SMD ASSY KEYBOARD FOR AD03 "ROHS" 1.00
33
3
023232302 PCB CEM 1L 1.6mm 291x36mm REV.0.01 KEY "ROHS" 1.00 5k
34 112210000 RES SMD 0805 1/10W 1% 0R "TAD" CJ10-000F "ROHS" 6.00 5000
35 411024148 DIODE SMD SOD-80 MINIMELF 75V 150mA "GOOD-ARK" LL4148 "ROHS" 50.00 2500

Akai MPK MINI Specifications

General

Mixer section	-
Product color	Black
Number of drum pads	8
Built-in display	No
MIDI out	Yes
USB connector type	Mini-USB
USB ports quantity	1
Current	0.1 A
Input voltage	5 V
Power supply type	USB

Weight and Dimensions

Depth	43 mm
Width	306 mm
Height	180 mm
Weight	700 g
