Akai MPK MINI Service Manual

36 711048401 CONNECTOR SMD 5943XXOHDOR-16P 16PIN P=1.0mm "MEILI" 1.0-16PX "ROHS" 1.00
37 105-AD07-61 PCB ASSY MAINBOARD FOR AD07 "ROHS" 1.00
38 105-AD07-51 PCB SMD ASSY MAIN FOR AD07 "ROHS" 1.00
39 023243005 PCB FR4 2L 300.5*76.5mm MAINBOARD V0.06 FOR AD07 "ROHS" 1.00
40 110008000 FERRITE BEAD SMD 1806 800R @100MHz 1A "FENGHUA" CBW451616U851 "ROHS" 1.00
41 113004602 FERRITE BEAD SMD 0603 4*600R 100MHz 300mA "FENG HUA" CBA321609-4U-601B "ROHS" 8.00 4000
42 113016000 FERRITE BEAD SMD 0603 600R GZ1608U601 "SUNLORD" "ROHS" 1.00 4000
43 113111002 RES SMD 0603 1/16W 1% 10K "ROHS" 2.00 5000
44 113131501 RES SMD 0603 1/16W 5% 1.5K "FENGHUA" "ROHS" 1.00 5000
45 113230220 RES SMD 0603 1/10W 5% 22R "ROHS" 2.00
46 133130472 RES NETWORK SMD 0603*4 4.7K 1/16W 5% "ROHS" 4.00 5000
47 134130470 RES NETWORK SMD 0603*4 1/16W 5% 47R "FENGHUA" "ROHS" 4.00 5000
48 134131002 RES NETWORK SMD 0603*4 1/16W 5% 10K "FENG HUA" "ROHS" 2.00 5000
49 134134104 RES NETWORK SMD 0603*4 1/16W 5% 100K "FENGHUA" "ROHS" 2.00 5000
50 210201106 CAP SMD ELEC 10UF 4*5.5mm 16V 20% "ROHS" 2.00 4000
51 210211107 CAP SMD ELEC ALUMINUM 100UF 16V 20% 6.3*5.4mm "ROHS" 2.00 4000
52 210226016 CAP SMD ELEC 50V 20% 1UF 4*5.5mm "ROHS" 2.00 4000
53 213102200 CAP SMD 0603 CER 20PF 20% 25V "ROHS" 2.00 4000
54 213102391 CAP SMD 0603 CER 20% 25V 390PF "ROHS" 16.00 4000
55 213104103 CAP SMD 0603 CER 10NF 10% 50V X7R "FENG HUA" "ROHS" 1.00 4000
56 213119104 CAP SMD 0603 0.1UF 10% 25V X7R "ROHS" 10.00 4000
57
3 310611171B IC SOT-223 "N.S" LM1117IMPX-3.3V/ LM1117MPX-3.3 "ROHS" 1.00 2500
58
311807416B IC SO14 "PHILIPS" 74HC164D "ROHS" 2.00
59 411024148 DIODE SMD SOD-80 MINIMELF 75V 150mA "GOOD-ARK" LL4148 "ROHS" 10.00 2500
60 411060000 LED RED 15mA SMD 0603 HIGHILIGHT "JASIONAL" JX-SP190URC "ROHS" 20.00 3000
61 421013904 TRANS SMD SOT-23 XTR SS NPN 250MHz "PHILIPS" 404 MMBT3904 "ROHS" 16.00 3000
62 511071009 INDUCTOR SMD 1206 10uH 10% "FENGHUA" CMI321609X100KT "ROHS" 1.00 4000
63 551038004 CRYSTAL 8MHz+/-25PPM 22PF HC-49/S-SMD "DONGGUANG" CXSD-008000000-D200GD75 "ROHS" 1.00 1000
64 711048401 CONNECTOR SMD 5943XXOHDOR-16P 16PIN P=1.0mm "MEILI" 1.0-16PX "ROHS" 1.00
65 721509900 USB JACK SMD MUSB-BSF-105 5PIN "CHUNSHENG" MUSB-B-105-EP "ROHS" 1.00 1000
66 Y324710386 IC MPU PROGRAMMING 32-BIT 64K FLASH 3.3V 48MHZ W/USB LQFP-64 "ST" STM32F103R8T6TR CONSIGN "ROHS" 1.00
67 Y314710386 IC MPU 32-BIT 64K FLASH 3.3V 48MHZ W/USB LQFP-64 "ST" STM32F103R8T6 CONSIGN "ROHS" 1.00
68 152132103 POT 10K B "POLYSHINE" F-09KH B10K L15FCX6 "ROHS" 8.00 1000
69 812121000 SCREW ST2.5*12mm +P/B D=5mm BLACK ZINC "ROHS" 7.00
70 812127000 SCREW ST2.5*8mm +P/B D=5mm BLACK ZINC "ROHS" 33.00

Akai MPK MINI Specifications

General

Mixer section	-
Product color	Black
Number of drum pads	8
Built-in display	No
MIDI out	Yes
USB connector type	Mini-USB
USB ports quantity	1
Current	0.1 A
Input voltage	5 V
Power supply type	USB

Weight and Dimensions

Depth	43 mm
Width	306 mm
Height	180 mm
Weight	700 g
