Akai MPK Road 88 - Page 14

1 PT1504412701 Key Bed Cap 1
18
2 PT15044127 Key Bed Cap 1
1 PT15106301 Button(B;clear) 6
5
1 PT153006801 Pitch Mod housing(Printing-painting) 1
7
2 PT1530068 Pitch_Mod housing 1
1 RU1504414 Rear Plug 1
29
1 RU1504417 Rubber Pad 2
39
1 RU1504419 Rubber Mat 2
40
1 SC0306RINI Screw M3X6 PPN 10
23
1 SC0308RBNI Screw M3X8 PRN Tapping 7
10
1 SC0410BIBI Screw M4*8MM PBB 3
8
1 SC0419PW12BBI Screw M4x19 φ12PPWB W/Washer Tapping 17
17
1 SC0420PW11IBI Screw M4x20 PPWB 16
16
1 SC0430FICI Screw 2
33
1 SC3510BABI Screw 12
12
1 SC3516BABI Screw 13
1 TWNM1530307 Box Assembly 1
2 NM1530110 Top Housing(Wood Veneer+Flannel) 1
1
2 NM1530307 Bottom Housing 1
14
1 TWPC17A01501 Main PCB Assembly 1
2 PC17A015 Main PCB 2-Layer FR-4 301*112mm 1.6t 1
Lead-free HASL
2 TWPC17A015A01 Main PCB Assembly 1 6
3 AL1-60-7473 ECAP LOW ESR 470uF/16V SMD-F 2 EC16,EC17
3 AL1-71-3102 Solid Tantalum Electrolytic 1 EC5
Capacitors10uF/16V 20% B-SMD
3 AL2-51-4401 Transistor 2N4401 NPN SOT-23 (Transistor 7 Q1,Q2,Q3,Q4,Q5,Q6,Q8
MMBT4401LT1 NPN SOT-23)
3 AL2-61-7223 IC NJU7223DL1-33 3.3V TO-252 1 U12
3 AL2-69-2464 IC 1 U14
3 AL2-71-1324 IC LMV324 SOP-14 2 U2,U4
3 AL2-71-3079 IC MC33079 QUAD OP-AMP SOP-14 2 U6,U10
3 AL2-73-4051 IC74HC4051 Single 8-Chan Mux 16P Soic 1 U3
3 AL2-75-4344 IC CS4344-CZZ 24bit 192KHz Stereo D/A 2 U7,U11
Converter TSSOP-10
3 AL2-85-0403 IC TPS60403 1 U8
3 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 24 C17,C18,C27,C28,C34,C35,C40,C41,C68~C83
3 CS102J5003NPO CCAP SMD 1nF/50V 5% 0603 NPO 4 C19,C30,C37,C42
3 CS103K5003X7R CCAP SMD 0.01uF/50V 10% 0603 X7R 1 C13,C21
3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 38 C1,C2,C5~C10,C12,C14,C15,C16,C20,C22,C24
C25,C36,C38,C39,C43~C53,C55~C59,C62
C63,C65
3 CS105K1603X5R CCAP SMD 1uF/16V 10% 0603 X5R 2 C54,C64
3 CS106K0605X5R CCAP SMD 10uF/6.3V 10% 0805 X5R 1 C31
3 CS225K1605X7R CCAP SMD 2.2uF/16V 10% 0805 X7R 5 C23,C26,C29,C66,C67
3 CS300J5003NPO CCAP SMD 30pF/50V 5% 0603 NPO 2 C60,C61
3 CS330J5002NPO CCAP SMD 33pF/50V 5% 0402 NPO 2 C84,C85
3 CS471J5003NPO CCAP SMD 470pF/50V 5% 0603 NPO 2 C32,C33
3 DIEN1N4148WSM Diode SMD 6 D1,D2,D3,D4,D5,D6
3 DIZDSMAJ5ASM TRANSIENT VOLTAGE SUPPRESSOR DIODE 1 D7
SMAJ5A-13-F MIL-STD-22
3 ECS10710D Capacitor Electrolytic 100UF 10V SMD-D 4 EC3,EC6,EC25,EC27
