Akai STB-2380 User Manual

7
User manual
2 Setup
This chapter describes how to connect your receiver to the TV with the par
ticular
equipments for gaining optimum signal quality. The receiver provides various interfaces
to connect to the TV or ot her devices. Select the most appropriate procedure
depending on the equipment you have.
Note: If you encounter any problems setting up your receiver, please contact
y
our local
receiver distributor.
2.1 Connecting the Antenna
Connect your aerial to the ANTENNA IN as follows.
2.2 Connecting the TV
2.2.1 Using HDMI Cable
The HDMI connection is recommended for Digital TV. In case the TV has a HDMI inpu
t
connector, a special all-digital interface that provides the highest picture quality,
connect
the receiver to the TV with the HDMI cable as follows.
HD1080P
CAUTION
HD OUT
COAXIA L
RF IN
~90 -240V
50/ 60Hz
HD DVB-T2 RECEIVER
POWER CONSUMPTION: 10W
~90-240V 50/60HZ
STANDBY CONSUMPTION: 1W
RF OUT
SCART
ON
OFF
CAUTION
HD OUT
COAXIA L
RF IN
~90 -240V
50/ 60Hz
HD DVB-T2 RECEIVER
POWER CONSUMPTION: 10W
~90-240V 50/60HZ
STANDBY CONSUMPTION: 1W
RF OUT
SCART
ON
OFF

Akai STB-2380 Specifications

General

Brand	Akai
Model	STB-2380
Category	Receiver
Language	English
