Akai STB-2380 User Manual

User manual
8
2.2.2 Using SCART Cable
Connect the receiver and the TV using an SCART cable.
TV
2.3 Powering On
1. Connect the power cord of the receiver to a wall outlet.
2. Push on the power button located at the left side on the front panel of the receiv
er.
Note
:
The type of power cord varies depending on area. Select the appropriate ty
pe for
your country .
CAUTION
HD OUT
COAXIA L
RF IN
~90 -240V
50/ 60Hz
HD DVB-T2 RECEIVER
POWER CONSUMPTION: 10W
~90-240V 50/60HZ
STANDBY CONSUMPTION: 1W
RF OUT
SCART
ON
OFF
SCART OUT
