Model No: AC -S13CK_S13HK
Version 1.0
CHAPTER 5: REFRIGERATION CYCLE
1. Cooling only appliance
ÖÆÀäϵͳͼ
Indoor unit
evaporator
liquid side
gas side
3-way valve
2-way valve
Outdoor unit
accumulator
compressor
condenser
capillary
