AKO AKO-D14632 - Display Messages

D146H002 Ed.02
Flashing 0: Access code (Password) request
You must enter the access code configured on L5 to execute the requested
function (p. 9 and 23).
See also parameter P2 (p. 27)
Probe 1, 2 or 3 faulty
(open circuit, crossover or temperature outside the probe limits; NTC: -50
To 99 ºC; PTC: -50 To 150 ºC).
Indicates a defrost is underway. After defrosting, the message will continue
to be displayed during the time specified in parameter d3 (see Chapte 4.2).
ting with temperature:
Maximum temperature in control probe alarm. Temperature set in A1 has
been reached (p. 17) .
(Activates alarm relay)
Alternating with temperature:
Minimum temperature in control probe alarm. Temperature set in A2 has
been reached (p. 17)
(Activates alarm relay)
Alternating with temperature:
External alarm activated (by digital input) (p. 17)
(Activates alarm relay)
Alternating with temperature:
Severe external alarm activated (by digital input) (p. 17)
(Activates alarm relay)
Alternating with temperature:
Defrost alarm time-out. Displayed when a defrost ends after the maximum
time elapsed as defined in parameter d1. (p. 17)
(Does not activate alarm relay)
Alternating with temperature:
Door open alarm. Shown if the door remains open longer than specified in
parameter A12 (p. 17)
(Does not activate alarm relay)
Alter
alarm relay)
nating with temperature:
Pump down malfunction error (Stop) (p. 17).
(Does not activate
Alternating with
y)
temperature:
Pump down malfunction error (Start up) (p. 17).
(Does not activate alarm rela
2.2.- Display messages
