NOTE: When ordering replacement tips check retaining ring (#17) and O-Ring (#19)
** For other threads order by description and thread size (ODM and TPI) or by Akron Thread Code.
†† Package of 50 Ball Bearings - P/N 109041.
† Parts included in Pitot Blade Replacement Kit - P/N 110086. Kit includes reusable
Alignment Fixture - P/N 7-12-269
* Tips not part of standard unit. Only tips in standard units are U.L. Classified.
Parts List
ITEM NO. DESCRIPTION PART NUMBER QUANTITY
1 3/4”/19mm tip 9015-0015 1
1 15/16”/23.8mm tip* 9015-0016 1
1 1”/25mm tip* 9015-0017 1
1 1 1/8”/28.5mm tip 9015-0018 1
1 1 1/4”/31.8mm tip* 9015-0019 1
1 1 1/2”/38.1mm tip 9015-0020 1
1 1 3/4”/44.5mm tip 9015-0021 1
1 1 7/8”/47.6mm tip* 9015-0024 1
1 2”/50.8mm tip 9015-0022 1
1 2 1/4”/57.2mm tip 9015-0023 1
2 Body 110283 1
3 Set Screw 7-42-023 1
4 2 1/2” Inlet Swivel (NH) ** 101420 1
5 Gasket 7-17-043 1
6 Ball Bearings †† 39
7 Bleeder Valve 7-79-045 1
8 Thumb Screw 7-67-110 1
9 Pitot Adapter Tube 110098 1
10 Stop Screw 7-67-111 1
11 Pressure Gauge - PSI/kPa 7-18-183 1
12 Quick Connect - 1/4” Socket 7-07-169 1
13 Quick Connect - 1/4” Plug 7-07-170 1
14† O-Ring 7-57-022 1
15† Set Screw (cup point) 7-65-024 1
16† Pitot Blade 110087 1
17 Retaining Ring 7-56-089 1
18 Lock Ring 109227 1
19 O-Ring 7-57-239 1
20† Set Screw (dog point) 7-65-117 1
21 O-Ring 7-57-052 1
22 Label 7-73-247 1
– Carry Case w/Liner 7-07-311 1
– Instruction Manual 7-04-607 1
– Laminated Discharge Table 7-07-328 1
3
