Akron SABERMASTER 1577 - Dimensional Specifications

Page 5
135135flfl MAXIMUM MAXIMUM
13 1/32 13 1/32
36 7/8 36 7/8
10 31/32 10 31/32
Figure 1
DIMENSIONAL
SPECIFICATIONS
WARNING
▲
!
WARNING
▲
!
Note: View in unlocked position Adjustable to any round aerial ladder rung up to 1
7
⁄8” dia.
Rung spacing should not exceed 16” on centers for 2
1
⁄2”
and 3” swivel, 14
7
⁄16” on centers for 3
1
⁄2” swivel.
Danger Zone
Elevation Stops
