Akuvox E12S - Installation Guidance; Installation Environment Recommendations; Akuvox E12 Wall Mounting Steps

2
Indoor and outdoor installation are supported.
If installing the device outdoors, please don’t place device under direct sunlight,it will bring a bad effect or be broken with
the high temperature.
If installing the device indoors, please keep device at least 2 meters away from light, and at least 3 meters away from
window and door.
E12
According to the position of the
reserved wires on the wall, stick
the wall-mounting template vertically
to ensure that the wires can come out
of the shadow position of template.
Drill (6 mm drill bit required) four screw
holes with a depth of 25mm in the screw
holes of the template.
Insert four plastic wall anchors into the
holes.
Fix the wall-mounting bracket on the
wall by tightening four ST4x20 screws
to the plastic wall anchors.
Backlight Direct sun
through window
Close to lightDirect sunlight Indirect sunlight
through window
