Translation of original user instructions
Removing the blades (Fig. I)
Before removing the blades, check their instal-
lation position!
1. Unscrew and remove the hexagon bolt (1).
2. Carefully pull the ball bearing (2) off the shaft (8).
3. Pull the thrust ring (3), washer (4) and short
spacer tube (5) off the shaft.
4. Pull off the blades (6) and long spacer tubes one
after another.
Install in the reverse sequence.
Help in case of malfunctions
Malfunction Help
Motor does not
run
Check the power cable and
the residual-current circuit
breaker
Push the operator presence
control towards the top
handlebar.
Select a lower working depth.
Shaft does not
rotate
Select a lower working depth.
Clear the blades.
Contact a customer service
workshop.
The motor is
losing power
Select a lower working depth.
Renew worn blades.
Clean the housing.
Mow the lawn (grass is too
long).
Poor scarifying
performance
Select a lower working depth.
Renew worn blades.
Machine is
not running
smoothly
Machine is
vibrating
Damaged blades.
Contact a customer service
workshop.
Malfunctions that cannot be rectified using this table
must be attended to by an authorised specialist work-
shop.
Disposal
Do not dispose of worn-out machines or
spent batteries (including rechargeable
batteries) in domestic waste!
The packaging, machine and accessories are made
from recyclable materials and must be disposed of
accordingly.
