GB
14 HW 3000-3500 | HW 3000-3500 INOX | HW 3300 INOX
Product description
IMPORTANT! Denotes a situation which can
result in material damage if not avoided.
NOTE Special instructions for ease of under-
standing and handling.
2 PRODUCT DESCRIPTION
Various models of pumps are described in these
operating instructions. Identify your model from
the identification plate.
2.1 Scope of supply
The pump is supplied with pressure switch, pres-
sure gauge and mains cable.
2.2 Product overview
No. Component
1 Pump inlet/suction line connection
2 Filling screw
3 Pump outlet/pressure line connection
4 Motor housing
5 Pump base
6 Storage vessel
7 Pressure gauge
8 Drain plug
9 Mains cable
10 Pressure line (accessory)
11 Elbow nipple (accessory)
12 Seal (accessory)
13 Connecting nipple (accessory)
14 Seal (accessory)
15 Filter (accessory)
16 Suction line (accessory)
2.3 Function
The device is used for supplying water in and
around the house. After commissioning, the de-
vice switches the pump on and off, depending on
the pressure. The pump draws water via the suc-
tion line and conveys it to the storage vessel.
When the storage vessel is full, the pump switch-
es off again. If water is drawn off, the pump
switches on again automatically and conveys wa-
ter to the tapping point. The storage vessel is
then filled again.
2.4 INOX (stainless steel)
Pumps with the designation "INOX" are made of
stainless steel. This does not affect their design
or function.
2.5 Safety and protective devices
Thermal protection switch
The pump is fitted with a thermal protection
switch which switches the motor off in the event
of overheating. After a cooling-down phase of ap-
prox. 15 - 20 minutes the pump switches on
again automatically.
2.6 Pressure sensor
The pump is equipped with a pressure sensor.
This sensor automatically switches the pump off
and on when the set pressure is reached.
■
Set pressure: see technical data.
2.7 Intended use
The pump is intended for private use in house
and garden. It must only be operated within the
scope of its usage limitations in accordance with
the technical data.
The pump is suitable for:
■
Watering the garden and premises
■
Domestic water supplies
■
Water supply pressure boosting.
NOTE The local regulations must be ob-
served if the pressure of the water supply is in-
creased. Information is available from your local
plumbing specialist.
The pump is suited exclusively for the conveying
of the following fluids:
■
Clear water, rainwater
Any use not in accordance with this designated
use shall be regarded as misuse.
2.8 Possible misuse
The pump must not be used in continuous opera-
tion. It is not suitable for conveying:
■
Drinking water
■
Salt water
■
Foodstuffs
■
Dirty water containing paper and textile resi-
dues
■
aggressive media, chemicals
■
corrosive, flammable, explosive or fuming fluids
■
fluids that are hotter than 35 °C
■
water containing sand and abrasive fluids.
