To Next PageTo Next PageWhat causes end galling of cross and cups on my Alamo Lawn Mower?
If you're experiencing end galling of the cross and cups on your Alamo Lawn Mower, it could be due to the speed being too high. Reduce speed to the rated RPM. Also, the load may be too high for the joint, so check for small joint angles.
What to do if blade bolts keep working loose on my Alamo Lawn Mower?
If the blade bolts on your Alamo Lawn Mower are working loose, there are a few possible reasons. First, ensure that the bolts are tightened to 300 ft./lbs. If the bolt hole is elongated or oversized, you will need to replace the blade carrier. Lastly, a worn-out locknut should be replaced.
Why is the slip clutch slipping on my Alamo A84B Lawn Mower?
If the slip clutch on your Alamo Lawn Mower is slipping, it could be due to several reasons. An excessive load may be the cause, so try reducing speed and/or raising the cutter. Weak springs can also cause slipping, so consider replacing them. Check for improper adjustment and re-adjust the slip clutch if needed. If there's too much power for the material intake, reduce ground speed and adjust the slip clutch. Worn or oil-contaminated friction facings should be replaced. If the friction facings are glazed, clean them with emery cloth.
Why is the gearbox on my Alamo A84B so noisy?
If your Alamo Lawn Mower's gearbox is noisy, it could be due to improper backlash, rough gears, or a worn bearing. For improper backlash, consult your local Alamo Industrial Dealer. If the gears are rough, try running them in or changing them. A worn bearing should be replaced.
How to stop breaking blade bolts on my Alamo A84B Lawn Mower?
If you are breaking blade bolts on your Alamo Lawn Mower, ensure you are not operating with loose blade bolts by tightening them to 300 ft./lbs. Also, check for worn blade bolts and replace them as needed.
Why is my Alamo A84B Lawn Mower gearbox leaking oil?
If the gearbox on your Alamo Lawn Mower is leaking, several issues could be the cause. A damaged oil seal will need to be replaced. If the shaft is bent, replace both the oil seal and the shaft. A rough oil seal race can be addressed by replacing the shaft or repairing the race. Ensure the oil seal is installed correctly; if not, replace it. If the oil seal isn't sealing in the housing, replace it or use a sealant on the O.D. of the seal. An oil level that's too high should be corrected by draining the oil to the proper level. Damaged gaskets should be replaced, and loose bolts need tightening. If there's no oil seal, install one. Using oil that is too light requires using EP140 instead. Loose bearings need adjustment, and a stopped-up vent plug should be opened.
Why is my Alamo Lawn Mower not cutting?
If your Alamo Lawn Mower is not cutting, several factors could be the cause. The blades might be dull, requiring sharpening or replacement. Ensure you're using the correct blade for the carrier and that you're using fan blades in grassy conditions. Check that the carrier RPM isn't too low, and increase the PTO speed if necessary. Also, make sure the mower is level, adjusting it if needed, especially in heavy weeds. Other potential causes include tractor tires mashing down the grass, requiring an offset adapter, or ground speed being too fast, which can be resolved by shifting to a lower gear. Check if the blades are locked back and free them. Also, inspect the blade bolts for wear, and replace them if the blades are riding up. Replace any bent blades. If blades wear fast, increase the cutt...
What causes needle rollers to brinnell into the cup and cross on my Alamo A84B?
If the needle rollers have brinnelled into the cup and cross on your Alamo Lawn Mower, it's likely due to the load being too high for the joint. Use a protective device. Also, check the joint angles and phasing.
What causes broken cross or cups on my Alamo Lawn Mower?
If the cross or cups are broken on your Alamo Lawn Mower, it may be because the load is too high for the joint. Use a protective device with the joint. Check joint angles and phasing, and slow down or raise the mower.
What causes rapid clevis wear on my Alamo A84B?
If you're experiencing rapid clevis wear on your Alamo Lawn Mower, ensure that washers are installed above and below the drawbar. If the clevis is bending or spreading, make sure the pin or bolt is tightened, using a 1" gr5 or 8 bolt and tightening the nut. If the tongue is bending or binding in turns, add an attaching plate to all 3-Point drawbars.
General| Brand | Alamo |
|---|---|
| Model | A84B |
| Category | Lawn Mower |
| Language | English |
