Alarm.com LTE Module | Reference Manual
Mode or four seconds in PowerSave Mode. It also occasionally flashes in
patterns to indicate Z-Wave status. See the table below for a description of
various possibilities.
Table 3: Z-wave LED status indicators
LED 2
LED 5
Device status or error
Description
4-blink
Add Mode (lasts 120
seconds or until a device
is added)
In this mode you can add a
device to the local Z-Wave
network. Devices cannot be
added to a network if they
are already a part of a
network
2-blink
Delete Mode (lasts 120
seconds or until a device
is deleted)
In this mode you can delete a
device from a Z-Wave
network. A device can only
be in one network at a time,
and must receive a “delete”
command before it can be
learned into a new network
Solid
Successful add
node/remove
node/replication (lasts
60 seconds)
After receiving this signal
leave all devices by the LTE
module for 1 minute. Locks
must be left next to the
module for 4 minutes
Solid
with
one
blink
Add node attempt failed
because node already in
network (lasts 60
seconds)
Device you attempted to add
to a network is already in a
network, and must be
“deleted” before it can join a
new network
2-blink
No other nodes are in
the network (lasts until a
device is added to the
network)
No devices have been added
that can be controlled by the
LTE module yet. See above
for instructions on how to
add devices
5-blink
Learn mode error (lasts
60 seconds)
The device was not
successfully added to the Z-
Wave network.
6-blink
No Home ID present
(lasts until the module
connects to Alarm.com
and is configured)
When the LTE module first
connects to Alarm.com it is
configured with a necessary
unique network ID
LED L3 (yellow)
L3 flashes with every communication between the module and its radio unit
in Idle Mode, and with every communication with Alarm.com in Connected
Mode. In PowerSave Mode, this LED flashes in unison with LED 2.
LED L4 (green)
L4 indicates the LTE signal level as a number of flashes (0 to 5 bars). The
number of bars may not correspond to the bars shown on your cell phone. A
level of 5 bars is obtained only in the strongest signal conditions.
Signal level is updated every ten seconds if it fluctuates, or every 30 seconds
if it is fairly stable.
If L4 is not flashing it indicates one of the following states:
• The module is in PowerSave Mode
• The module just powered up
• There is no LTE coverage in the area. Alarm.com recommends a steady
signal level of 2 or higher for proper operation of the module.
In Connected Mode, the LED toggles on and off.
LED L5 (yellow)
L5 indicates Z-Wave errors. See Table 2 above for more details.
Various Module States (modes)
There are three module states, or modes, as described below:
Idle Mode. AC power is OK and the module is not currently talking to
Alarm.com.
L1 - Flashes errors, if any.
L2 - Communication with panel.
L3 - Communication with radio unit.
L4 - Signal level (0 to 5 bars).
L5 – Flashes errors, if any
PowerSave Mode. The module just powered up, AC power is down, or AC
power was recently restored and the battery is recharging. The module is
fully functional and will go into Connected Mode as soon as a signal needs to
be sent. Press and hold the 5 Key for 10 seconds to switch the module into
Idle Mode and update the signal level reading. The system will go into Idle
Mode every 2 hours to check for any incoming messages.
L1 - Inactive.
L2 - Communication with panel.
L3 - Same flashing pattern as L2.
L4 - Inactive.
L5 - Inactive
Connected Mode. The module is currently talking to Alarm.com. The
module stays in Connected Mode for at least four minutes after reporting
an event to Alarm.com, unless the 5 Key is pressed and held for 10 seconds,
which will cause the module to go back to Idle Mode.
L1 - Flashes errors, if any.
L2 - Communication with panel.
L3 - Communication with Alarm.com.
L4 - Alternates two seconds on, then two seconds off.
L5 - Inactive
Sleep Mode. The panel is not connected to AC power, or there is an AC
power failure, and the battery level is low. The module will connect to
Alarm.com to send a signal, but will otherwise draw almost no power.
Note: If the LTE module is powered down for a short period of time, buffered
messages from Alarm.com may be received when module power is restored.
