8. Below is an example image of the inside of the enclosure after installation of the hard drives. The label side of the
hard drives should be facing up.
9. Slide the top cover back onto the chassis. Using a screwdriver, re-install screws onto the sides and back of the
chassis.
10. Enroll the device. For more information about how to enroll the device, see Commercial Stream Video Recorder
(ADC-CSVR2000P/2008P/2016P) - Installation Guide.
To replace failed hard drives
1. Verify that the device has no power and is unplugged.
2. Using a screwdriver, remove the screws on the sides and back of the chassis.
3. Remove the top cover of the chassis.
4. Using a screwdriver, remove the screws from the bottom of the chassis to loosen the hard drives.
https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Video_Devices/Commercial_Stream_Video_Recorder_(…
Updated: Thu, 14 Apr 2022 20:22:51 GMT
