AlarmNet 7845C - Wiring and Programming Guides by Panel Type; Vista 10, Vista 20 and Via 30 Panels

4. Wiring and Programming Guides By Panel Type
Vista 10, Vista 20 and Via 30 (Non-E2 Panels)
Programming the Panel
*25 WIRED EXPANSION/RELAY USED . . . . . . . . . . . . . . . . . . . . . .[0]
0 = none; 1=4219; 2=4229; 3=4204
*80 OUTPUT RELAYS
Notes:: 1. Field *25 must be programmed for a 4229 (Relays 01 and 02) or a 4204
(Relay 01 to 04)
2. Tampers of contacts or expansion units cannot be used to operate
relays.
Where: A = RELAY ACTION 0 = No Response; 1 = Close for 2 sec;
2 = Close and stay closed; 3 = Pulse on and off
EV = EVENT 0 = Not Used; 1 = Alarm; 2 = Fault; 3 = Trouble
ZL = ZONE LIST 1,2, or 3 (from Field *81) or 0 = Not Used.
START ZONE LIST: Upon alarm, fault, or trouble of ANY
zone on this list, relay action will START
STOP
“RESTORE of” ZONE LIST: Upon restore of ALL
zones on this list, relay action will STOP. It need not be
same list as used for START
ZT= ZONE TYPE/SYSTEM OPERATION
Choices for Zone Types are:
00 = Not Used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .06 = 24 Hr Silent
01 = Entry/Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .07 = 24 Hr Audible
03 = Perimeter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .08 = 24 Hr Aux
04 = Interior Follower . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .09 = Fire Trouble
05 = Trouble Day/Alarm Night . . . . . . . . . . . . . . . . . . . .10 = Interior w/Delay
Choices for System Operation are:
20 = Arming - Stay . . . . . . . . . . . . . . . . . . . . . . . . . . . .36 = At Bell Timeout**
21 = Arming - Away . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38 = Chime
22 = Disarming (Code + OFF) . . . . . . . . . . . . . . . . . . . . . .39 = Any Fire Alarm
31 = End of Exit Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40 = Bypassing
32 = Start of Entry Time . . . . . . . . . . . . . . . . . . . . . . . .41 = AC Power Failure
33 = Any Burglary Alarm . . . . . . . . . . . . . . . . . . . . .42 = System Battery Low
34 = Code + # + 7 Key Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58 = Duress
35 = Code + # + 8 Key Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
**Or at Disarming, whichever occurs earlier
ZONE TYPE
/SYST OP’N
(ZT)
S T A R T
either or both
S T O P
either or both
OUTPUT
RELAY
RELAY
ACTION
(A)
EVENT
(EV)
ZONE
LIST
(ZL)
ZONE TYPE
/SYST OP’N
(ZT)
“RESTORE of”
ZONE LIST
(ZL)
01
02
03
04
