Premium Volleyball & Badminton Set
Assembly
3. GUIDE ROPE ATTACHMENT
A. Insert the guide rope (#10) into the eye bolt that is mounted at the top of the
pole (#2) as shown in FIG. 3. The pre-attached tension clips and stakes should
be attached after the guide rope has been threaded through the eye bolt.
Secure eye bolt with the wing nut and tighten the wing nut so that the loop
is positioned vertically as shown in FIG. 3. Pull the net upward and hook the
connecting cord loop onto the lower wing nut loop, in order to secure the net.
The pole cap (#1) can now be placed onto the top pole (#2). See FIG .3A.
B. Insert the second guide rope (#11) through the eyebolt and place the eyebolt
through the hole in the second pole (#3). Once completed, secure the eyebolt
with the wing nut.
FIG. 3
FIG. 3A
Tension Clip
Stake
Eyebolt
Guide Ropes
Wing Nut
Second Guide Ropes
10
3
11
Pole Cap
Connecting
Cord Loop
1
2
FIG.3A
