6. In order to expel air, press on the drain valve 16 on the pneumatic gun and
check the pressure on the manometer.
7. Set the On/Off switch to the “0” position as soon as the desired or maximum
permissible working pressure has been reached.
8. If you no longer wish to use the compressor, pull the mains plug and follow the
steps described in the chapter “Switching the compressor on and off”.
Inflating tyres with an adapter
An 8-piece adapter set is included in the product contents. You can use the adapters to
inate bike tyres, air maresses and other products.
The following overview shows you which adapters are suitable for which purposes.
Valve adapter Use
Express valve adapter 11 Bicycle valve (Sclaverand valve, Dunlop valve)
Ball needle 12 Balls
Screw-on valve adapter 4 Screw-on valves (rubber boats, kayaks, pools or similar)
Conical universal adapter 9 and
10
inflatable mattresses, or similar
Bleed adapter 5 for vent valves (e.g. for a flock bed)
8 mm-adapter 6 All valves with an inner diameter > 8 mm (air
mattresses, pools, or similar)
■ To open the valve, push the valve cap together
slightly before you insert the adapter..
If you want to inate products with the enclosed adapters, proceed as follows:
1. Make sure that the On/Off switch 1 is set to the “0” position (see Fig. A).
2. Insert the mains plug in a socket.
3. Push the quick-release with lever 19 down.
4. Fit the nozzle adapter 8 on the pneumatic gun 15 .
5. Screw the desired adapter into the nozzle adapter (see the table above).
6. Make sure that all connections are secure.
7. Insert the adapter in the valve.
8. In order to switch on the compressor set the On/Off switch to position “1”.
You can read the operating pressure on the manometer 7 .
9. In order to expel air, press on the drain valve 16 on the pneumatic gun and
check the pressure on the manometer.
Operation
22
