Assembly
18
• The spotlight works best if the sensor area of the motion
sensor is crossed horizontally. As far as possible, install the
motion sensor in such a way that the main direction of
approach is not straight in front of the sensor.
Assembly
WARNING!
Risk of electric shock!
Improper installation may result in an
electric shock.
− Ensure that there are no cables or other
electrical lines behind the location
where the spotlight is attached.
To avoid triggering the spotlight unintentionally,
the spotlight must be fitted firmly. If the spotlight
moves, this has the same effect as moving heat
sources in the sensor area.
Mounting the spotlight
1. Choose a suitable surface for installation (see chapter
section “Choosing an installation location”).
2. If necessary, remove the rear panel
5
from the spotlight
by unscrewing both fixing screws
2
.
3. Hold the rear panel on the installation surface and mark
both locations for fastening. Use a spirit level if necessary.
