The rechargeable battery is only precharged to a low level.
Therefore, charge the rechargeable battery before first use.
1. Insert the mains plug of the charger (16) in the socket.
2. Push the rechargeable battery release button (11) and pull the re -
chargeable battery (8) out of the rechargeable battery holder (10).
3. Plug the connector of the charging cable (15) into the charging
socket (9) of the rechargeable battery.
4. The charge indicator will initially illuminate in red. The charge
indicator will turn green once the rechargeable battery is fully
charged. During the charge process, the mains plug, charger and
rechargeable battery will warm up. This is due to operational
reasons and is not a defect.
5. Let the rechargeable battery cool down to room temperature if it
heats up during the charging process.
6. Pull the main plug off the charger out of the socket.
7. Pull the connector of the charging cable out of the rechargeable
battery.
8. Slide the rechargeable battery into the rechargeable battery holder of
the cordless hammer drill until it audibly locks into place (see fig. 2).
The cordless hammer drill is now operational.
Operation
Risk of injury!
If you use the cordless hammer drill improperly, you could
hurt yourself and other persons. The drill bit will heat up
during operation.
Operation
22
