4
7. charge contacts
8. battery compartment
9. microphone
10. battery-indication ( ): see next
page
11. power on/off
12. talk back
13.
1. sound indication LED’s
2. volume up; up button when
programming
3. volume down; down button when
programming
4. button to set the sensitivity
5. link-check ( ), see below
6. loudspeaker
2 OVERVIEW
2.1 OVERVIEW PARENT UNIT:
1
5
4
3
2
10
11
8
7
12
6
9
Link check :
• ashes green when there is no link between baby unit and parent unit
or parent unit is out of range with the baby unit.
• steadily green when linked to the baby unit
• steadily red in FULL ECO MODE and the baby is asleep. Attention: in
this mode there is no active link.
• steadily orange in FULL-ECO-MODE and the baby is crying. The
baby-unit is linked to the parent-unit.
