Observe the color of the rivet on the power spring
cassette. Identifies the power spring
)
Use care during assembly of sheave and power spring
onto base and shaft assembly . Ratchet can interfere
waith pawl.
)
Lubricate seal component with oil prior to assembly
(high and medium pressure swivels). Damage to seal
component can occur.
)
Apply a high quality thread sealant or teflon tape to
component that attaches to main shaft. Product leak-
age can occur.
)
Inspect low pressure swivel body and stud prior to kit
installation. Mating surfaces are subject to wear.
)
Remove power spring tension prior to reel disassembly.
Personal injury can occur.
Service hints
Refer to the overhaul procedures for details.
