WIRING CONNECTIONS
H8/6 VIOLET/BLACK
Wire
(Timer Control Channel 4 / Key Sensor Output)
The VIOLET/BLACK wire provides a 200mA (-) negative programmable
ground output for a variety of optional devices. The output on the
BLACK/VIOLET wire is programmable from 1 to 120 seconds. (See
programming instructions). This wire can be used to open a sunroof,
or any power device you choose to control. The VIOLET/BLACK wire
must be wired to a relay when powering any devices. Note: factory
default setting is a 1 second momentary ground. (See programming
instructions for operation of this output)
Note: this wire can also be programmed as a second start crank
output. (See programming instructions). Some vehicles require a
second starter wire to be energized, or on certain GM vehicles what is
known as the bulb check wire must receive a ground signal while the
starter is cranking. When using this wire as a second start wire (Most
Nissan vehicles) a relay must be used to energize this circuit. To activate
this featyre, press the transmitters
and buttons at the same time.
H8/7 RED/WHITE
Wire
(Channel 3 Trunk Output)
The RED/WHITE wire will provide a 1 second 200mA (-) negative
ground pulse output by activating channel 3 on the transmitter for 2
seconds. This feature will allow a trunk release or other optional devises
to activate by remote transmitter. . Note: If not attaching the
RED/WHITE wire directly to the BCM (Body control module) a
relay must be used to power the trunk or device being energized.
H8/8 LT.GREEN / BLACK
Wire
( Step 2 Door Unlock / Factory Disarm
Shock Sensor Bypass)
Dual Pulse Door Unlock Output
The dual pulse door unlock feature will work for most of the fully electronic
door lock circuits. When wired for this feature, pressing the disarm (or
unlock) button one time will disarm the alarm and unlock the driver's
door only. If you press disarm (or the unlock) button two times within
3 seconds, the alarm will disarm and all the doors will unlock. This is a
(-) negative output.
