18
WIRING CONNECTIONS
H8/3 BROWN/BLACK
Wire
(Horn or Factory Rearm Output)
The BROWN/BLACK wire provides a 200mA (-) negative output for
hooking up to the vehicles horn relay activation wire. This wire can also
be programmed to use as a factory rearm wire. When programmed for
factory rearm a (-) negative pulse is provided after the remote starter
times out or is shut down with the transmitter. Note: factory default
setting is for horn output. (See programming Alarm Feature #3.)
Factory Security Rearm Signal Output ( H8/3 BROWN/BLACK
Wire)
This (-) negative output is programmable. If programmed for rearming
a factory installed security system. This wire will supply a pulse whenever
the remote start times out or is shut dowm using the transmitter and
remote door locking.
H8/4 BLACK/WHITE
Wire
(Dome Light Supervision Output)
The BLACK/WHITE wire provides a 200mA (-) negative output for 30
seconds when the doors are unlocked using the transmitter. The
BLACK/WHITE wire will also flash the dome light circuit for the same
duration as the siren when violated. Note: If not attaching the
BLACK/WHITE wire directly to the BCM (Body control module) a
relay must be used to power the dome light circuit.
H8/5 BLACK/RED
Wire
(Timer Control Channel 5 Programmable Output)
The BLACK/RED wire provides a 200mA (-) negative programmable
ground output for a variety of optional devices. The output on the
BLACK/VIOLET wire is programmable from 1 to 120 seconds. (See
programming instructions). This wire can be used to open a sunroof,
or any power device you choose to control. The BLACK/RED wire must
be wired to a relay when powering any devices.
Note: factory default setting is a 1 second momentary ground.
(See programming instructions.)
To activate this feature press the transmitters
and buttons at the
same time.
