2 Press the valet/program switch 6 times and hold it in on the 6
th
press until 3 chirps followed with 1 long chirp is heard and the LED
turns on then release the valet/program switch. You are now in the
ALARM FEATURE #3 PROGRAMMING MODE.
3 Press and release the transmitter button that corresponds to the feature
you desire to program.
PROGRAMMING
ALARM FEATURE #3 PROGRAMMING CHART
One Chirp with
Press One LED Pulse
Transmitter Factory Default Two Chirps with Three Chirps with Four Chirps with
Button Setting Two LED Pulses Three LED Pulses Four LED Pulses
1 H2/5 Brown H2/5 Brown H2/5 Brown H2/5 Brown
Wire=Constant Wire=5-second Wire=Random Wire=Horn
Siren Output Pulse Siren Pulse Siren Output
Output Output
2
H8/8 Lt. Green/ H8/8 Lt. Green/ H8/8 Lt. Green/
Black Wire= Black Wire= Black Wire= Start
Factory Security Dual Pulse Door Status Output
Disarm Signal Unlock Output (Shock Sensor
Output Bypass)
3
H5/8 White/Black H5/8 White/Black H5/8 White/Black
Wire=1 Pulse Wire= 2 Pulses Wire= 3 Pulses
Activate Activate Activate
4
H8/3 Brown/ H8/3 Brown/
Black Wire= (-) Black Wire=
200ma Horn Factory Security
Output Rearm Signal Output
5
+ H8/6 Violet/ H8/6 Violet/ H8/6 Violet/ H8/6 Violet/
Black Wire Black Wire Black Wire Black Wire
Channel 4 Output= Channel 4 Output= Channel 4 Output=
Channel 4 Output=
Momentary Latched Output Latched Output & Timer Programm-
Output Reset with Ignition ing (set to any
on interval between
1 sec. and 2 min.)
5 Chirps =H8/6 Violet/Black Wire = Ground Output During Start (crank)
