29
3-c. Press and release the transmitters
and
buttons together 4 times,
[4] LED flashes and [4] siren or horn chirps will indicate you are
in CHANNEL 6 TIMER PROGRAMMING MODE.
4. Press and hold the valet/program switch, the timer will immediately
start.
5. When the desired interval has passed, release the valet/program
switch. 1 long chirp will be heard for confirmation. (Set to any
interval between 1 second and 2 minutes.)
Note 1:
If your built-in timer controls the windows or a sunroof in your vehicle, DO
NOT change the timer setting! This requires installer-only programming.
Changing the value will adversely effect operation and may cause damage
to the motors.
Note 2:
Momentary output The momentary output selection will provide a negative
signal from the Channel 4 (5/6) output immediately when the channel 4
(5/6) button is pressed and will continue until the button is released.
Latched output The latched output selection will provide a negative signal
as soon as the Channel 4 (5/6) button is pressed and will continue until the
button is pressed again
Latched output / reset with ignition The latched / reset with ignition
output selection operates just like the latched output but will reset or stop
when the ignition is turned on.
Ground Output During Start (Crank) This wire will provide a 200 mA
(-) negative ground output while the starter output of the control module
is active. This output can be used to activate the Crank Low/Bulb Test wire
found in some GM vehicles. This wire is also referred to as the ECM wake
up wire in some vehicles.
START FEATURE. # 1 PRORAMMING:
1. Turn the Ignition from ON to OFF 3 times, then to the OFF
position.
2. Press the valet/program switch 8 times and then hold it in on the
8
th
press until four chirps followed with 1 long chirp is heard and the
LED will turn on, release the valet/program switch. You are now in
the START FEATURE #1 PROGRAMMING MODE.
3. Press and release the transmitter button that corresponds to the feature
you desire to program.
PROGRAMMING
