33
4. Within 10 seconds, start the vehicle with the key. (While the engine is
running, the parking lights and LED will flash, If not, please check
VIOLET/WHITE wire connection. (H5/9)
5. Press and hold the valet/program switch for 2 seconds or until 1 long
chirp and the LED lights constant for two seconds. The RPM signal is
learned.
6. Turn OFF the ignition switch to SHUT DOWN the engine.
Once you complete step 6, you can adjust and test the Check Level
as below:
CHECK LEVEL PROGRAMMING: (TEST and ADJUST)
1. Press the
button twice on the transmitter to start the vehicle.
2. If the engine starts:
a. Press the
button twice on the transmitter to stop the engine. You
have completed this programming successfully.
b. Press the
button on the transmitter to exit the program mode. There
will be 3 long chirps and 3 parking light flashes for confirmation.
3. If the crank time is too short, (Engine not running, but stops cranking):
a. Press the
button on the transmitter to turn off the ignition.
Press the
button on the transmitter to set the proper Check
Level to Hi position. [2] LED flashes and [2] chirps will confirm
this setting.
b. Repeat the step1 4.
4. If the crank time is too long, (if the engine is running successfully, but
the starter still cranks):
a. Press the
button on the transmitter to stop.
Press the
button on the transmitter to set the proper Check Level
to Low position. [1] LED flash and [1] chirp will confirm this setting
b. Repeat the step1 4.
ENGINE CHECKING VOLTAGE
1. Turn the Ignition 'switch ON and OFF 3 times and leave it in the
OFF position.
2. Press the valet/program switch 10 times and then hold it in on the
10
th
press until five chirps with 1 long chirp is heard, release the
valet/program switch.
3. Press the transmitters
and buttons at the same time to set the
Engine Checking Voltage. [1] LED flash, and [1] chirp to confirm
this setting
Once you complete step 3, you can adjust and test Start Timer as
follows:
PROGRAMMING
