Alert 650R - DIAGNOSTICS & TESTING; SHUTDOWN DIAGNOSTICS

. .
37
SHUTDOWN DIAGNOSTICS
The unit has the ability to report the cause of the last shutdown of
the remote starter system.
1. Turn the Ignition switch to the ON position.
2. Press the
button on the transmitter.
3. The LED will now report the last system shutdown by flashing
for one minute in the following grouped patterns:
SHUTDOWN DIAGNISTICS
LED
Flashes Shutdown Mode
1 (-) Safety Shutdown 1.Close the Hood
Input (Hood) 2.Check H5/1 GREY wire connection
2 (+) Safety Shutdown Input 1.Set the Hand Brake (if installed)
(Brake) or Hand Brake (if 2.Check H5/2 BROWN/RED wire
installed or connection.
Neutral Safety Switch 3.Move the Enable Toggle Switch to
input fail ON position. (if installed)
4.Move the gear selector to Park/
Neutral position.
5.Check H5/3 THIN BLACK wire
connection.
3 No RPM (Engine Checking Check H5/9 VIOLET/WHITE wire
TACH) or connection.
Low Voltage. (Engine Program the CHECK LEVEL from
Checking Voltage) or Hi Check Level to Low Check Level
Oil Sensor (Engine Check H5/9 VIOLET/WHITE wire
Checking Oil Sensor) connection.
4 Wait-to-start time out Check H5/5 GREY/BLACK wire
connection
5 Over-rev
6 System timed out
7 Transmitter
8 Tach. Signal has not been Re-learning the RPM (Start
learned feature #2-2)
