Description of Controls – Chapter 5
MidiVerb 4 Reference Manual 47
Page 4: Modulators. This is where you select the two MIDI modulation sources
which will be used for all Programs to control their parameters. The parameters these
control depend on the selected Program’s Configuration. For example, in all Reverb
Configurations, Modulator X controls the Reverb Decay Time, while Modulator Y
controls the Wet/Dry Mix. Either Modulator can be assigned to: Pitch Bend,
Aftertouch, Note Number, Velocity or a Controller from 000–119. Each Modulator’s
amplitude can be set between -99 and +99. The default settings are: Mod#X = 001
(modulation wheel), Mod#Y = 007 (volume), Amp X and Y = 000. For more
information and a list of the modulated parameters in each Configuration, see
Chapter 6.
Mod#X AmpX Mod#Y AmpY
Page 5: Program Table. The Program Table allows you to intercept incoming
program change messages and have them recall specific Programs (in either the
Preset or User bank) which may not be the same number as the program change
message received. There are 128 different possible MIDI program change messages
(000 – 127). However, the MidiVerb 4 has 256 Programs to choose from. Therefore,
the Program Table allows us to choose which of the 256 Programs will be recalled
when certain program change numbers are received. The first value in the display
indicates the MIDI program change you wish to remap (000—127). The second value
indicates the Program you wish to be recalled (00—127 Preset (Pset) and 00—127
User). You can remap each of the 128 program change numbers, if so desired.
Program Tbl: MIDI User
If the D parameter is lowered below User 000, the display will change from User to
Pset to indicate that you are now assigning an incoming program change number to a
Program in the Preset bank.
Program Tbl: MIDI Pset
Page 6: Sends Sysex. This page lets you dump out all 128 User Programs or the
current Program being used/edited, or the Program Change Table (see above). The
data is sent as Sysex information. This can be sent to a MIDI storage device, or to
another MidiVerb 4. Select either All or Buffer (the currently selected Program which
is in the edit buffer), or Table. When this page is selected, the [UTIL] button will flash
to indicate that pressing the [UTIL] button starts the MIDI dump. The display will
read “Transmitting Sysex...” and the [UTIL] button will flash quickly, indicating that
all 128 User Programs are being sent out the [MIDI OUT] connector. See Chapter 6 for
more information regarding MIDI applications.
Send MIDI Sysex:
or to copy a Program to a different location. When pressed for the first time, the
Program. At this point, you can choose to alter the Program’s name, and/or choose a
different location to store the Program into. When you’re ready to store, press the
