Level 1 BOM
Part # Part Name Description
10550002 Metal Plate DN-SE002,SPCC,T=3mm,black zinc plate,V1.0
20070023 Left Side Panel DN-PC7019,left side panel,ABS(UL94HB),black, chrome plate,ROHS,V1.0
20070024 Right Side Panel DN-PC7020,right side panel,ABS(UL94HB),black, chrome plate,ROHS,V1.0
20080031 Back Panel DN-PC8029,ABS(UL94HB),black, texture,ROHS,V1.0
20110099 Lens DN-PL1080,lens, texture,V1.0
20210136 Rotary Cap DN-PN2098,ABS(UL94HB),black, chrome plate,ROHS,V1.0
20300107 Feet black rubber,Φ8-5mm,one side glued,V1.0
54110016 Lens DN-PL1081,PC,T=1mm,with silkscreen,V1.0
54280003 Front Panel DN-EC013,ABS(UL94HB),black, with silkscreen,V1.0
70010810 Full Threaded Screw M3*6mm,hexagon,D5.5,black zinc
70010811 Full Threaded Screw M2.6*6mm,cross screw,D4.0mm,black zinc
CR010583 RoHS Semi Assembled: LXAM MAIN ASSY
CR010584 RoHS Semi Assembled: LXAM MAIN SMT ASSY
16160008 USB Cable AN-U0008,UL2725,28#,1000MM, USB-A MINI USB-5P
22010710 Safety Manual ALESIS, Safety Manual,7-51-0154-R
22010831 User Guide LXAM, User Guide,V1.0
23031168 Master Carton A=A,V1.0
23090490 Giftbox 300G+CE，V1.0
90021186 Specific Sticker LXAM,55*13mm,V1.0
90041259 Barcode Sticker 90*42mm,V1.0
90080001 Destination Sticker GA0/GA1/GA2
90200056 Marking Sticker BLACK&361C,Φ30mm,V1.0
90220078 Unique Sticker ALESIS,30*30mm,PANTONE 361C,V1.0
