Engineering BOM
Item Part Name Description Qty
1 Rotary VR RD902F-20E1-15F-B10K-00D28(艾华） 2
2 SMD Resistor 1/10W,0Ω,±5%,0603 5
3 SMD Resistor 1/10W,22.1Ω,±1%,0603,编带式 2
4 SMD Resistor 1/10W,47Ω,±5%,0603 6
5 SMD Resistor 1/10W,220Ω,±5%,0603 1
6 SMD Resistor 1/10W,470Ω,±1%,0603,编带式 2
7 SMD Resistor 1/10W,1KΩ,±1%,0603,编带式 19
8 SMD Resistor 1/10W,1.5KΩ,±5%,0603 4
9 SMD Resistor 1/10W,4.42KΩ,±1%,0603 2
10 SMD Resistor 1/16W,10KΩ,±1%,0603 9
11 SMD Resistor 1/10W,11KΩ,±5%,0603 2
12 SMD Resistor 1/10W,12.7KΩ,±1%,0603 2
13 SMD Resistor 1/10W,15KΩ,±1%,0603 4
14 SMD Resistor 1/10W,20KΩ,±1%,0603 1
15 SMD Resistor 1/10W,62KΩ,±1%,0603 1
16 SMD Resistor 1/10W,100KΩ,±1%,0603 6
17 SMD Resistor 1/10W,820KΩ,±5%,0603 4
18 SMD Resistor 1/10W,1MΩ,±1%,0603 1
19 SMD Resistor 1/8W,33.2Ω,±1%,0805 2
20 SMD Resistor 1/8W,47Ω,±5%,0805 2
21
SMD Ceramic Electrolytic
Capacitor
10PF,VDC50,±5%,NPO,0603,编带式 5
22
SMD Ceramic Electrolytic
Capacitor
18PF,VDC50,±5%,NPO,0603,编带式 2
23
SMD Ceramic Electrolytic
Capacitor
33PF,VDC50,±5%,NPO,0603,编带式 5
24
SMD Ceramic Electrolytic
Capacitor
101,VDC50,±5%,NPO,0603,编带式 12
25
SMD Ceramic Electrolytic
Capacitor
221,VDC50,±5%,NPO,0603,编带式 2
26
SMD Ceramic Electrolytic
Capacitor
102,VDC50,±10%,X7R,0603,
编带式 4
27
SMD Ceramic Electrolytic
Capacitor
103,VDC50,±10%,X7R,0603,编带式 1
28
SMD Ceramic Electrolytic
Capacitor
104,VDC25,±10%,X7R,0603,编带式 33
29
SMD Ceramic Electrolytic
Capacitor
1UF,VDC10,±10%,X7R,0603, 编带式 4
30
SMD Ceramic Electrolytic
Capacitor
471,VDC50,±5%,X7R,0805,编带式 4
31
SMD Ceramic Electrolytic
Capacitor
1UF,VDC16,±10%,X7R,0805,编带式 1
32
SMD Ceramic Electrolytic
Capacitor
2.2UF,VDC50,±10%,X7R,0805,编带式 2
33
SMD Ceramic Electrolytic
Capacitor
4.7UF,VDC10,+80/-20%,Y5V,0805,编带式 1
34
SMD Ceramic Electrolytic
Capacitor
10UF,VDC10,+80/-20%,Y5V,0805,编带式 2
