Engineering BOM
Item Part Name Description Qty
35
SMD Tantalum Electrolytic
Capacitor
10uF/16V,±20%,-40/+105℃,C型,黑色,冠佳 2
36 SMD Crystal Resonator HC-49SMD-24.0000MHz,20PF 1
37 Beads 1K_at_1G Wurth Electronics741861210 0603 8
38 Beads 1000OHMS WIDE BAND，WURTH742792662 1
39 Beads
MURATA，BLM15HD601SN1，1400OHMS@1GHz，0.85OHM DCR
300mA 0402
1
40 SMD Inductor 1000uH,SFIH127T-102M（奋发） 1
41 Ultra Electrolytic Capacitor 22uF/16V,±20%,-40/+85℃,Φ4*7mm,P=1.5mm,黑色,剪脚为4mm 10
42 Ultra Electrolytic Capacitor 47uF/6.3V,±20%,-40/+85℃,Φ4*7mm,编带式P=1.5mm,黑色 2
43 Ultra Electrolytic Capacitor 220uF/16V,±20%,-40/+85℃,Φ6.3*7mm,P=2.5mm,黑色,剪脚为4mm 1
44 Diode SOT23,BAV99,FAIRCHILD 1
45 Diode SOT23,BAT54S,编带式 2
46 Diode MMBD4148LT1,SOT23,DIODES,编带式,荃发 5
47 Diode LL-34,1/2W,12V,编带式 1
48 NPN Transistor MMBT4401LT1,SOT23,ONSEMI 1
49 PNP Transistor MMBT4403LT1,SOT23,ONSEMI 3
50 NPN Transistor 2SD2114K，SOT23 4
51 Optocoupler IS181GB,SMD,ISOCOM 1
52 IC USBLC6-2-SC6,ST 1
53 IC FDC6306P,SOT-6,FAIRCHILD 3
54 IC LP2985AIM5,LP2985AIM5-3.3 SOT23-5,NS 1
55 IC SN74LVC1G17DCK,SC70-5,TI 1
56 IC MFI337S3959 1
57 IC AK4386 , TSSOP-16 1
58 IC MCP6002 SOP8 4
59 IC TPS60150 QFN 2x2-6 1
60 IC CY8C3446LTI-073,QFN-48,CYPRESS 1
61 Male Socket AN-JP418,2021-02,高勇/柏盛(P=2mm,180度)1
62 S Terminal AN-J0709,SW-5-07,正威 2
63 6.35 Socket AN-J0350,SJ6305-5P(配螺垫).正威 4
64 USB Socket AN-J4303,Y11-213,MINI USB 5P/F 90度B型两脚,佑德利 1
65 Connector P102-1*5,崧辉
(单排,90度,P=2.0mm,5PIN) 1
66 Connector P=1.27MM，L=13MM 10P,2*5,180度（崧辉） 1
67 Connector AN-JP107,P=2.0,H=4.4,1x5P,S/T,维峰 1
68 USB Cable
AN-W1506,L=1800mm,UL2725 28# OD=3.5mm,慧晴 一端带USB-
A公端,另一端带mini USB-B公端
1
69 30pin connector mfi512s0017-30pin 1
70 8PIN connector mfi677-0637-c10a 1
71 USB Cable
L=1000mm,UL2725 28# OD=3.5mm,一端带miniUSB-
B,另一端Lightning接口
1
72 IPOD Cable
一端MFI512S0017 30PIN
Apple母座，另一端miniUSB,L=1000MM（待定）
1
73 PCB FR4四层板，128MM*72MM*1.6MM，绿色,1盎司 1
74
Mechanical Parts
75 Side Panel DN-PC7019,左侧板,ABS(UL94HB),黑色,表面抛光电镀黑镍,ROHS,V1.0 1
76 Side Panel DN-PC7020,右侧板,ABS(UL94HB),黑色,表面抛光电镀黑镍,ROHS,V1.0 1
