Alesis iO Dock II Service Manual

3
ICBA05FP IC (SMD 5V) 1 IC9
3
ICCS4270-CZZR IC CS4270-CZZR TSSOP-24 1 U1
3
ICLM3578A IC LM3578A SOP-8 1 U7
3
ICMFI337S3959-1 IC MFI337S3959 USON-8(YAHORNG) 1 IC5
3
ICTLV70033DDCT IC TLV70033DDCT SOT23-5 1 IC1
3
ICTPS2557DRBR IC TPS2557DRBR SON-8 1 IC7
3
ICYH102M20 IC(MCF51JF128VLH+Program)LQFP-64 1 IC3
4
ICMCF51JF128VLH IC MCF51JF128VLH LQFP-64 1 (IC3)
3
ICYH102M21 IC(MCF51JU64VLF+Program)LQFP-48 1 IC2
4
ICMCF51JU64VLF IC MCF51JU64VLF LQFP-48 1 (IC2)
3
JK6LJB0669CKA12 6.3φ JACK 13Pin 90° Female 1 J7
3
JK8KD-01DH-2.0
DC Jack 90 。 2.0mm
1 J8
3
JKA03M8007PS1YH XLR JACK 11PIN 90° Female COMBO 2 J13,14
3
RS000004J06 RES 0Ω 5% SMD 1206 2 R170,181
3
RS000010J03 RES 0Ω 5% SMD 0603 5 R23,27,28,182,204
3
RS000110J03 RES 1Ω 5% SMD 0603 3 R36,37,40
3
RS001010F03 RES 10Ω 1% SMD 0603 10 R45,46,66,70,71,90,91,186~188
3
RS001K10F03 RES 1K 1% SMD 0603 16 R3,8,14,16,54,55,79,80,122~125,134,135,172,178
3
RS001M10F03 RES 1M 1% SMD 0603 3 R42,154,192
3
RS002K10F03 RES 2K 1% SMD 0603 6 R1,12,51,52,76,77
3 RS003310F03 RES 33Ω 1% SMD 0603 17 R4,5,9,11,15,30,44,62,141,142,144,145
R147,159,161,167,200
3 RS004702F20 RES 47Ω 1% SMD 2010 2 R206,207
3 RS004704F06 RES 47Ω 1% SMD 1206 2 R24,26
3 RS010010F03 RES 100Ω 1% SMD 0603 6 R35,60,129,151,158,205
3 RS010K10F03 RES 10K 1% SMD 0603 31 R7,13,25,29,34,38,41,65,92,97,106~111
R126,143,146,153,155,157,160,164,165
R171,177,185,198,199,203
3 RS010M10F03 RES 10M 1% SMD 0603 1 R189
3 RS015K10F03 RES 15K 1% SMD 0603 11 R43,85,103,112,117,120,121,156,173,193,194
3 RS01K510F03 RES 1.5K 1% SMD 0603 6 R63,69,81,84,102,163
3 RS033010F03 RES 330Ω 1% SMD 0603 2 R53,78
3 RS03K910F03 RES 3.9K 1% SMD 0603 1 R174
3 RS047K10F03 RES 47K 1% SMD 0603 4 R104,105,132,133
3 RS04K710F03 RES 4.7K 1% SMD 0603 9 R67,68,82,149,152,190,191,201,202
3 RS07K510F03 RES 7.5K 1% SMD 0603 8 R56~59,83,86~88
3 RS100K10F03 RES 100K 1% SMD 0603 11 R6,64,94,99,118,119,128,179,180,195,196
3 RS13K710F03 RES 13.7K 1% SMD 0603 2 R96,101
3 RS1K2110F03 RES 1.21K 1% SMD 0603 4 R49,50,74,75
3 RS20K510F03 RES 20.5K 1% SMD 0603 2 R93,98
3 RS3K3210F03 RES 3.32K 1% SMD 0603 2 R61,89
3 RS3K6510F03 RES 3.65K 1% SMD 0603 2 R95,100
3 RS3K9210F03 RES 3.92K 1% SMD 0603 4 R47,48,72,73
3 RS42K210F03 RES 42.2K 1% SMD 0603 1 R176
3 RS47K510F03 RES 47.5K 1% SMD 0603 2 R183,184
3 RS510K10F03 RES 510K 1% SMD 0603 1 R39
3 RS5K4910F03 RES 5.49K 1% SMD 0603 1 R175
3 RS8K4510F03 RES 8.45K 1% SMD 0603 1 R168
3 SW8216-B2C01 Switch Power Push Single Row 1 SW1
3 SWDS-11L-10K Switch SLIDE 2P2T 3 S1~3
3 TE612000402 Terminal(4P)180° 2 TE1,3
3 TE622001201 Pin Header 90° Pitch:2.00mm Single Row 1 TE2
12P DIP
