Alesis iO Dock II Service Manual

3 AL2-51-4403 Transistor 2N4403 PNP SOT-23 6 Q3~6,16,18
3 AL2-54-0138 Mosfet BSS138 N-CH SOT-23 1 Q2
3 AL2-54-0856 Transistor BC856 PNP SOT-23 4 Q7~10
3 AL2-54-6306 Mosfet FDC6306P P-CH SSOT-6 1 U5
3 AL2-71-0072 IC TL072CDR Low-Noise Jfet-Input 1 U12
Operational Amplifiers Soic-8
3 AL2-71-3079 IC MC33079 QUAD OP-AMP SOP-14 3 U6,8,22
3 AL4-02-0007 Jack 1/4 Stereo 7-Pin Fem Mini W/Grnd 1 J3
Lug Straight
3 CN0720000801 Flat Cable 7Pin Pitch 2.0mm Single Row 1 CN201
Length 80mm Pin/Pin
3 CS047C5003NPO CCAP SMD 4.7pF/50V ±0.25pF 0603 NPO 3 C167~169
3 CS101J5003NPO CCAP SMD 100pF/50V 5% 0603 NPO 16 C42,43,54,55,82,83,88~91,140,141,144,145,154,155
3 CS102J5003NPO CCAP SMD 1nF/50V 5% 0603 NPO 2 C58,64
3 CS103J5003X7R CCAP SMD 0.01uF/50V 5% 0603 X7R 2 C105,109
3 CS104K5003X7R CCAP SMD 0.1uF/50V 10% 0603 X7R 50 C4,5,10~15,26,27,29~31,33,34,39,45,46
C56,57,59,61~63,80,81,86,87,95,96,100
C101~104,106~108,110~113,138,156,158
C161,162,166,CC02,CC04
3 CS106Z0603X5R CCAP SMD 10UF/6.3V +80/-20% 0603 X5R 1 C25
3 CS150J5003NPO CCAP SMD 15pF/50V 5% 0603 NPO 4 C47,48,139,150
3 CS180J5003NPO CCAP SMD 18pF/50V 5% 0603 NPO 1 C68
3 CS220J5003NPO CCAP SMD 22pF/50V 5% 0603 NPO 1 C163
3 CS221J5003NPO CCAP SMD 220pF/50V 5% 0603 NPO 2 C7,8
3 CS222J5003NPO CCAP SMD 2200P 50V 5% 0603 1 C65
3 CS300J5003NPO CCAP SMD 30pF/50V 5% 0603 NPO 4 C32,35,94,97
3 CS330J5003NPO CCAP SMD 33pF/50V 5% 0603 NPO 4 C36,38,98,99
3 CS470J5003NPO CCAP SMD 47pF/50V 5% 0603 NPO 6 C49,142,143,146,147,151
3 CS471J5003NPO CCAP SMD 470pF/50V 5% 0603 NPO 4 C16,66,69,71
3 DISDB1100SM Schottky Barrier Rectifiers Diode B1100 1 D22
3 DISDB540C-13-F Schottky Barrier Rectifier Diode B540C- 2 D14,15
13-F SMC
3 DISDBAT54SSM Diode BAT54S 30V 0.2A SOT-23 1 D8
3 DISDMBRA340T3G Shottky diode DISDMBRA340T3G SMD 3A 40V 1 ZD2
3
DISR26 Schottky Barrier Rectifier 1 ZD1
3
DITVSNUP2201SM Transient Voltage Suppressol Diode 2 D7,13
NUP2201MR6 TSOP-6
3
EC10735TLE Capacitor Electrolytic low ESR 100uF/35V 1 C70
6.3*11mm
3
EC22816 Capacitor Electrolytic 2200uF/16V 2 C44,60
3
EC33550TNP ECAP Nonpolar 3.3uF/50V 5×11mm DIP 3 C18,67,164
3
EC47663TS Capacitor Electrolytic 47UF/63V 5 C37,40,41,52,53
3
ECS10616B Capacitor Electrolytic 10uF/16V B type SMD 14 C1~3,6,9,28,114,115,159,160,EC1~4
3
ECS10725FLE E CAP 100UF/25V 8*10MM SMD LOW ESR 3 EC6,10,12
3
ECS15725F Capacitor Electrolytic LOW ESR 150uF/25V 1 EC13
F type SMD
3
ECS22616B Capacitor Electrolytic 22uF/16V B type SMD 5 C50,51,152,153,EC14
3
ECS22725F E CAP 220UF/25V 8*10MM SMD 4 EC5,7,8,9
3
ECS47616D Capacitor Electrolytic 47uF/16V D type SMD 1 C17
3
ECS47710FLE ECAP 470uF/16V 8x10mm SMD Low ESR 1 EC11
3
ICAP1501K5L ICAP1501K5L T0263-5L 1 IC6
3
ICAP1510SL-13 IC Pwm Control 3A Step-Down Converter 1 IC8
AP1510SL-13 SOP-8L
